Tab. 12-6: Application icons

12.9.3 Dialogs

The "Diagnostics and settings" dialog is used as operating and display element
of the control. It can be operated via the switches "Run" and "Stop" in the lower
section (modes of operations).
DOK-MLC***-INDRACTRLV4-IT02-EN-P
Icon Description
System firmware is loaded and ready. At least one PLC
application was started
System firmware is loaded and not ready. All loaded
PLC applications are stopped
The control startup was paused
Initial firmware is active
The following erros are signaled:
Version conflict: Version error between IndraControl
●
Systray and firmware
Windows reboot or shutdown
●
System firmware or initial firmware is not started
●
Context menu is disabled
If the error occurs again after the reboot, contact the
Bosch Rexroth service
General icon display, e.g. start of the SysTray
application, the control is in "System Error" mode, etc.
