IndraControl VPB 40.4
UL508 (Industrial Control Equipment)
●
C22.2 no. 142-M1987 (CSA)
●
UL file no. E210730
However, there can be combinations or extension stages with a limited or
missing certification. Thus, verify the registration according to the UL marking
on the device.
Loss of UL/CSA conformity due to modifications at the device
UL and CSA marking applies only to the device upon delivery. After
modifying the device, verify the UL and the CSA conformity.

9 Interfaces

NOTICE
Ensure that the functional earth is connected, as otherwise the electronics can
be destroyed by a potential difference between the operator display and the
control cabinet PC if the voltage supply is interrupted to only one device and
established again. A direct connection of the functional earth between the
operator display and the control cabinet PC is optimal. If the functional earth is
connected to a neutral point, the control cabinet PC and the operator display
have to be connected to this neutral point.
To avoid malfunctions, use only shielded cables and metallic or
conductive connector/coupling housings with large-area shield
support.

9.1 Overview

The following connections are available at the control cabinet PC:
Name at the Connection type
housing
X10 PC voltage supply:
24 V DC
XDP Connection for external monitor Display port socket,
XSER CDI interface, data
XVID CDI interface, image
DOK-MLC***-INDRACTRLV4-IT02-EN-P
Material damages to electronics due to missing
functional earth!
Connection type
(at the device)
Male connector
terminal PC4/3-
G7.62
(20-pin)
RJ45 socket, 8-pin RJ45 plug
RJ45 socket, 8-pin RJ45 plug
Bosch Rexroth AG
Interfaces
Mating connector or cable
(from outside)
Socket terminal
PC4/3-G7.62
Display port plug, (20-pin)
(Twisted pair, 8-wire)
(Twisted pair, 8-wire)
13/87
