Instructions for Use
Diffustik / Variant PFTstik
Serial no.: xx|8|401|yyy and 2401xxxxx
2
3
If possible, observe the sequence of the work steps, because
otherwise it is more difficult to assemble!
For the Diffustik variant resp. when the "CO Diffusion" option is
added to the PFTstik variant, the connection of the relevant
components is described in the separate IFU
Version: 8 | Release date: 16. August 2021
1b
2. Connect the connector cable of the
•
Add-on CO Diffusion.
b) until prod. 11 / 2018:
Screw shutter drive [3] on the shutter
cage [2] until stop
Slide the shutter cage into the
shutter head [1b]
By
slight rotation (to protect the O-Rings)
until stop
shutter drive [3]
with
three-pole socket on the flow unit -
central
Page 59
