Instructions for Use
Diffustik / Variant PFTstik
Serial no.: xx|8|401|yyy and 2401xxxxx
For the Diffustik variant resp. when the "CO Diffusion" option is
added to the PFTstik variant, the connection of the relevant
components is described in the separate IFU
Add-on CO Diffusion.

4.1.3.4 Connection on the Height-Adjustable Arm

For the Diffustik variant resp. when the "CO Diffusion" option is
added to the PFTstik variant, the connection of the relevant
components is described in the separate IFU
Add-on CO Diffusion.
Version: 8 | Release date: 16. August 2021
Connection sockets on the height-
adjustable arm
Gassample
(Connection CO Diffusion)
Flow unit
Gas supply CO Diffusion
Page 45
