Diffustik Device / Connections - GERATHERM Diffustik Instructions For Use Manual

For the Diffustik variant resp. when the "CO Diffusion" option is
added to the PFTstik variant, the connection of the relevant
components is described in the separate IFU
Add-on CO Diffusion.

4.1.3.3 Diffustik Device / Connections

Page 44
Serial no.: xx|8|401|yyy and 2401xxxxx
Device front view
LED
to show the power supply
Connections at the rear of the device
USB-Connection
Bus-Connection
for flow electronics
On / Off switch
Fuse
Input AC 230 V
Version: 8 | Release date: 16. August 2021
Instructions for Use
Diffustik / Variant PFTstik
