Page 1: Table Of Contents
7 USER MANUAL FOR DP C13.CAN CONTENT 7.1 Important Notice 7.6.3 Headlights / backlighting 7.2 Introduction of Display 7.6.4 Walk Assistance 7.3 Product Description 7.6.5 Selection mode 7.6.6 ”Service Tip” 7.3.1 Specifications 7.6.7 ”Error code” indication 7.3.2 Functions Overview 7.4 Display 7.6.8 Battery capacity indication... -
Page 2: Important Notice
• Do not clean the display with a steam jet, high-pressure cleaner or water hose. 7.2 INTRODUCTION OF DISPLAY • Model: DP C13.CAN BUS • The label marking is as follows: • The liquid crystal display is made of hard- ened PMMA, the key button is made of silicone rubber. -
Page 3: Product Description
7.3 PRODUCT DESCRIPTION 7.3.2 Functional Overview 7.3.1 Specifications • Speed display (switching between km and • Operating temperature: -20℃~45℃ miles). • Storage temperature: -20℃~50℃ • Battery capacity indication. • Waterproof: IP65 • The lighting system. • Bearing humidity: 30%-70% RH •... -
Page 4: Display
7.4 DISPLAY Speed display in real-time Display of battery capacity in real time Support level Speed display in real-time Speed unit Data: Display data, which corresponds to the current mode Unit indicator The display shows , if the light is on. 7.5 KEY DEFINITION Mode/System On/Off Down... -
Page 5: Normal Operation
7.6 NORMAL OPERATION 7.6.1 Switching the System ON/OFF 7.6.4 Walk Assistance Press and hold (>2S) on the display to The Walk assistance can only be activated turn on the system. Press and hold (>2S) with a standing pedelec. again to turn off the system. Activation: Press the continuously until If the "automatic shutdown time"... -
Page 6: Service Tip
7.6.6 ”Service Tip” If the “Service" function switch on, every 5000 km (the mileage of more than 5000 km) the indicator "mA" is displayed every time at switch on. The “Service" function can be turned off and on in the setting interface. See details for operation in “Setting”... -
Page 7: Settings
7.7 SETTINGS After the display is turned on, press and hold 7.7.1.2 Selections in km/Miles (>2S) the button at same time to When the system is on, press and hold (>2S) access the “Setting” interface. pressing the button at same time to ac- button, you can select and reset cess the “Setting”... -
Page 8: View Information
7.7.1.4 Set Auto Off 7.7.2 View Information When the system is on, press and hold (>2S) All data in this item cannot be changed, only to button at same time to be viewed. access the “Setting” interface, repetitively 7.7.2.1 Wheel Size press the button until the “oFt”... - Page 9 7.7.2.3 Controller Software info 7.7.2.5 Display Software info When the system is on, press and hold (>2S) When the system is on, press and hold (>2S) button at same time to ac- button at same time to cess the “Setting” interface, repetitively press access the “Setting”...
- Page 10 7.7.2.7 Sensor Software info 7.7.2.9 “Service Tip” When the system is on, press and hold (>2S) When the system is on, press and hold (>2S) button at same time to button at same time to ac- access the “Setting” interface, repetitively cess the “Setting”...
- Page 11 7.7.2.11 Battery Information NOTE: If no data is detected, "--" is displayed. When the system is on, press and hold (>2S) button at same time to access the “Setting” interface, repetitively press the button until the “b01” appears on the display (as shown below). And then press to view “Battery info”.
-
Page 12: Error Code Definition
7.8 ERROR CODE DEFINITION The display can show the errors of a pedelec. If an error is detected, one of the following error codes will be displayed. Note: Please read carefully the description of the error code. When the error code appears, please first restart the system. - Page 13 Error Declaration Troubleshooting 1. Turn off the system and let the pedelec cool The protection temperature inside down. the controller has reached its maxi- 2. If the problem persists, please contact your mum protection value retailer. Error with the temperature sensor Please contact your retailer.
- Page 14 Error Declaration Troubleshooting Detection circuit for 15V has an error Please contact your retailer. Detection circuit on the keypad has Please contact your retailer. an error WDT circuit is faulty Please contact your retailer. Total voltage from the battery is too Please contact your retailer.
