Page 1: Table Of Contents
CONTENT DP C15.UART CONTENT Content Button definition Introduction Normal operation Specifications Functions setting Functions overview Error code definition Normal indication area DISPLAY MANUAL DP C15.UART... -
Page 2: Introduction
② Second line: PD2528051105 - Parameter code ③ Content of QR code: DPC15P10102.1 PD2528051105 DPC15.U 1.1 602P1R3230002 A. First line (as below) DP C15.U 1.1 ① DP C15.U : BAFANG display model ② 1.1: Hardware version number DISPLAY MANUAL DP C15.UART... -
Page 3: Specifications
• Rated current: 10mA • Storage temperature: -30℃~70℃ • Maximum operating current: 30mA • IP level: IP65 • Power-off leakage current: ≤1uA • Storage ambient humidity: 30%-70% • Operating current which supplied to control- ler: 50mA DISPLAY MANUAL DP C15.UART... -
Page 4: Functions Overview
• Time indication for single riding. RIES. (Note: If the display has this function) • Trip indication (including single-trip distance, • Indication for the remaining distance. (Note: total distance and remaining distance). it needs the display supports this function) DISPLAY MANUAL DP C15.UART... -
Page 5: Normal Indication Area
Multiple function indication area interface) Power assistance level indication • Assistance level indication: Indicate the cur- rent level from level 1~ level 5, If no number is displayed, it means no power assistance. DISPLAY MANUAL DP C15.UART... -
Page 6: Button Definition
Turn off the light: When the headlight is on and press and hold the button “+”, the lumi- nance of the display backlight will increase and the icon of headlight will disappear. (The interface: mode of push assistance) DISPLAY MANUAL DP C15.UART... - Page 7 → “AVG”(average riding speed) → the error code interface. When failure hap- “RANGE”(remaining distance) → “CALO- pens, the rider shall stop riding immediately. RIES/CAL”(KCal) → “TIME”(riding time) → “POWER”(output power) → “TRIP”(single trip distance). (The interface: error code) DISPLAY MANUAL DP C15.UART...
-
Page 8: Functions Setting
“+” and “-” at the select to “BACK” → “EXIT” to exit back to same time means saving setting and exiting main interface. back to main interface). When resetting the DISPLAY MANUAL DP C15.UART... - Page 9 Press and hold “+” and (Battery information indication interface) “-” at the same time to exit back to main interface or select “BACK” → “EXIT” to exit back main interface. (Wheel size indication interface) DISPLAY MANUAL DP C15.UART...
- Page 10 (Display interface for record of error code) Absolute state of charge Cycle times Maximum not charging time Recently not charging time Number of bat- tery cell Voltage of cell 1 Voltage of cell 2 ……… ……… Voltage of cell n DISPLAY MANUAL DP C15.UART...
-
Page 11: Error Code Definition
ERROR CODE DEFINITION ERROR CODE DEFINITION This HMI DP C15.UART can indicate all errors occurring on the pedelec. Error Explanation Troubleshooting Brakes enabled Check whether a brake cable is stuck. Bring your Pedelec to your dealer or to a High voltage protection specialist to have the error fixed. - Page 12 NOTES DISPLAY MANUAL DP C15.UART...
