Page 1: Table Of Contents
CONTENT FiSHAW 2023 UB40 DISPLAY MANUAL CONTENT 1 Important Notice 6.3 Mileage mode and Speed mode 2 Introduction 6.4 Headlight /backlight 3 Product Description 6.5 Walk assistance mode 6.6 “SERVICE” indication 3.1 Performance 7 User Setting 3.2 Functions Overview 4 Indication Area 7.1 “SETTING”... -
Page 2: Important Notice
FiSHAW 2023 1 IMPORTANT NOTICE • Do not clean the Pedelec with a steam jet, All users must be aware of the high-pressure cleaner or water hose. Water following: may seep into the electrics or drive and • If the fault information cannot be rectified destroy the equipment. -
Page 3: Introduction
INTRODUCTION FiSHAW 2023 2 INTRODUCTION • Name: smart display and controller (HMI) • Cable label identification is as following: • Model: DP C18.CAN • The housing material is PC, the window is DPC18CP10101.0 high hardness glass, as following: PD051205 Note: Contents on this Label contains important information of this product. -
Page 4: Product Description
FiSHAW 2023 3 PRODUCT DESCRIPTION Functions Overview Performance • Speed indication (including maximum speed • Operating temperature: -20℃- 45℃ and average speed, unit switching between • Storage temperature: -20℃- 50℃ km and mile). • Water-proof grade: IP65 • Battery capacity indication. •... -
Page 5: Indication Area
INDICATION AREA FiSHAW 2023 4 INDICATION AREA Speed scale display Mode selection: single-trip distance (TRIP) → total distance ODO → maximum speed (MAX) → average speed (AVG) → remaining distance (RANGE) → energy consumption (CALORIES) → time (TIME). (Note: some functions may be unavailable) Indication for the current remaining capacity of battery. -
Page 6: Normal Operation
FiSHAW 2023 6 NORMAL OPERATION Power ON/OFF Press and hold (>2S) to power on the display, the display begins to operate. Press and hold (>2S) again to power off the display. If the "automatic shutdown" time is set to 5 minutes (it can be set in function "Auto Off"), the HMI will be automatically turned off within this set time, When it is not operated. -
Page 7: Headlight /Backlight
NORMAL OPERATION FiSHAW 2023 Headlight /backlight Press and hold (>2S) to turn on the backlight as well as headlight. Press and hold (>2S) again to turn off the backlight and the headlight. The brightness of back- light can be set in function“Brightness”. (If the display is turned on in a dark environment, the display backlight/ headlight will be turned on automatically. -
Page 8: Walk Assistance Mode
FiSHAW 2023 Walk assistance mode When your Pedelec is motionless, press button until the Walk assistance indicator is dis- played. At this point, long press button, the Pedelec enters the walk assistance mode, the indica- Release the button to stop this,if no any operations within 5s will automatically return to 0 level. -
Page 9: User Setting
USER SETTING FiSHAW 2023 7 USER SETTING “SETTING” interface “Display setting” interface After the HMI powered on, briefly In “SETTING” interface, briefly press (<0.5S) press(<0.5S) for two times to enter into to select “Display setting” and then the “SETTING”. Briefly press (<0.5S) briefly press (<0.5S) to confirm and enter to select and then briefly press (<0.5S) - Page 10 FiSHAW 2023 7.2.2 “Service Tip” --- turn on/off the 7.2.5 “MAX PAS” --- set riding mode Service indication Briefly press (<0.5S) to select “MAX Briefly press (<0.5S) or to select PAS”, and then briefly press (<0.5S) “SERVICE”, and then briefly press (<0.5S) to enter into the interface.
- Page 11 USER SETTING FiSHAW 2023 7.2.7 “SOC View” --- set indication mode 7.2.9 “AL Sensitivity” --- set light for battery capacity sensitivity Briefly press (<0.5S) to select “SOC Briefly press (<0.5S) to select “AL View”, and then briefly press (<0.5S) Sensitivity”, and then briefly press (<0.5S) enter into the interface.
- Page 12 FiSHAW 2023 After setting the password, the interface exit back automatically to original interface within two sec- onds. Briefly press for two times (< 0.5S) to exit back to main interface or select “BACK” → “EXIT” to exit back to main interface, as following: Reset password: After setting, the interface “Password”...
-
Page 13: Information" Interface
USER SETTING FiSHAW 2023 7.3.2 Check “Battery Info.” (Function not available for this model) 7.2.11 “Set Clock” --- time setting Briefly press (<0.5S) to select“Set Briefly press (<0.5S) to select “Bat- Clock”, and then briefly press (<0.5S) tery Info.” and briefly press (<0.5S) confirm. - Page 14 FiSHAW 2023 7.3.3 Check “Ctrl Info” 7.3.5 Check “Torque Info” Briefly press (<0.5S) to select “Ctrl Briefly press (<0.5S) to select Info”, and then briefly press (<0.5S) “Torque Info”, and then briefly press (<0.5S) confirm. If no data is detected, it displays to confirm.
-
Page 15: Error Code Definition
ERROR CODE DEFINITION FiSHAW 2023 8 ERROR CODE DEFINITION The HMI can show the faults of Pedelec. When a fault is detected, the icon will be indicated and one of the following error codes will be indicated too. Note: please read carefully the description of the error code. When the error code appears, please first restart the sys- tem. - Page 16 FiSHAW 2023 Error Explanation Troubleshooting Stop riding and bring your Pedelec to your specialist e- Fault with wheel speed sensor bike mechanic to have the error fixed or contact FiShaw. Stop riding and bring your Pedelec to your specialist e- Torque signal of Torque sensor bike mechanic to have the error fixed or contact FiShaw.
- Page 17 ERROR CODE DEFINITION FiSHAW 2023 Error Explanation Troubleshooting Replace the battery, if the problem is not eliminated, please contact your FiShaw representative. Voltage of single cell is too high Replace the battery, if the problem is not eliminated, please contact your FiShaw representative. Temperature of battery is too high Replace the battery, if the problem is not eliminated, please contact your FiShaw representative.
-
Page 18: Maintenance
FiSHAW 2023 9 MAINTENANCE • Do not use thinner or other solvents to clean any of the components. Such substances may damage the surfaces. • Do not use hard objects to operate the buttons and Display Screen. • Do not use high-pressure water spray in any position on controller components. - Page 19 ERROR CODE DEFINITION FiSHAW 2023 CONSUMER MANUAL – DP C18.CAN...
- Page 20 FiSHAW 2023 CONSUMER MANUAL – DP C18.CAN...
