3. Enter the password.
•
Use the default password (12345678) when you log in to the BLE-Admin application for the first time.
•
It is highly recommended that you change the password (see step 4).
4. On the main screen, configure the following:
Option
Reader Name
Password
5. Tap Set Configuration and configure the following:
Parameter
Protocol
Credentials reading
standards
www.rosslaresecurity.com
Remarks
Assign name to selected door reader
Change password
Options
Wiegand, OSDP, OSDP-SC, Clock and Data
125 KHz EM (ASK)
125 KHz (FSK)
ISO 14443A
ISO 14443B
ISO 15693
BLE Credential
Multi-Smart™ Readers Installation & User Guide
Remarks
Wiegand: 26, 32, 34, 40, 56, 64 bit
26 bit (default)
Toggle to select Reverse
OSDP-SC: Install mode (read/write)
OSDP addresses: 0-31
13 (default)
You can select multiple credentials.
All standards are selected by default.
5
125KHz (FSK) supports
Wiegand 26, 32, 34, 35, 37,
40, 48 bit.
