Parameter
Sector
General purpose
button
Light bar
Buzzer
www.rosslaresecurity.com
Options
Off, Key A. xxxxxx
Activation
Set key as bell
Keypad press duration (seconds)
Activation
Brightness level
Level
Multi-Smart™ Readers Installation & User Guide
Remarks
Off (default)
Key A: Must type 12 character key in Hex
format
Location:
•
1K card
•
•
•
•
4K card
•
•
•
On/Off
If set to Off, the following are hidden:
•
Set key as bell
•
Keypad press duration
•
6-Bit Wiegand Rosslare format
(default)
•
6-Bit Wiegand with Nibble + Parity Bits
•
8-Bit Wiegand Nibble Complemented
•
Single Key, 4-Bit Wiegand
0.25, 0.5, 0.75, 1, 1.25, 1.5, 2
0.25 (default)
On/Off.
On (default)
High, Medium, Low
Medium (default)
Off, High, Medium, Low.
High (default)
6
Sector [0-15]
Block
-
Sector 0, Blocks 1,2
-
Sector 1-15, Blocks 0-2
Byte [0-15] in each available block
Sector [0-39]
Block
-
Sector 0, Blocks 1,2
-
Sector 1-31, Blocks 0-2
-
Sector 32-39, Blocks 0-14
Byte [0-15] in each available block
When a sector is activated,
the ISO 14443A,
ISO 14443B, and ISO 18092
credential reading standards
are automatically set to OFF.
If necessary, select a
standard again.
