Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide
100Base-FX
SFP Port
1000Base-X
10GBase-R
SFP+ Port
1000Base-X

Rated voltage range: 100V to 240V
Power Supply
Maximum voltage range: 90V to 264V
Frequency: 50/60 Hz
Rated current:2A
Input Leakage
≤3.5mA
Current
EEE Supported
PoE Not supported
Power
42W
Consumption
Operating temperature: 0 º C to 50º C
Temperature
Storage temperature: -40 º C to 70º C
Operating humidity: 10% to 90% RH
Humidity
Storage humidity: 5% to 95% RH
Fan Supports adaptive speed adjustment
Temperature
Not supported
Alarm
GB9254-2008
EN 55032:2015+AC:2016
EN 61000-3-2:2014
EMC Standards
EN 61000-3-3:2013
EN 55035:2017
ETSI EN 300 386 V2.1.1 (2016-07)
Security GB4943-2011
Standards EN 62638-1
Dimensions
440 mm x 267.5 mm x 43.6 mm (with front panel )
(W x D x H)
Weight 3.35 kg
Product Appearance
On the front panel, the RG-NBS5200-24SFP/8GT4XS Ethernet switch provides 24 SFP ports (8 Gigabit combo ports)
and 4 SFP+ ports. On the back panel, it provides an AC power port.
Figure 1-5 Appearance of RG-NBS5200-24SFP/8GT4XS
latest information.
AC input
Product Overview
8
