Ruijie RG-NBS5200 Series Hardware Installation And Reference Manual page 7

Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide
LED
LED Panel Identification
System status LED Status
10/100/1000Base-T
Ethernet port status 1-24
LED
SFP+ port status
25F-28F
LED
1.2 RG-NBS5200-24SFP/8GT4XS
Technical Specifications
Model RG-NBS5200-24SFP/8GT4XS
CPU Built-in CPU, single-core processor, 800MHz
BOOTROM N/A
Flash Memory 256 MB
SDRAM DDRIII 512MB
See Appendix B.
The copper cable is not supported.
Optical Module
State
Off
Blinking green
(0.5Hz)
Blinking green
(10Hz)
Solid green
Off
Solid green
Blinking green
Off
Solid green
Blinking green
The supported module type may change at any time. Consult Ruijie Networks for the
Meaning
The switch is not receiving power.
The switch is running, but is not connected to
Ruijie Cloud.
The switch is being upgraded or initialized.
The switch is connected to Ruijie Cloud.
The port is not connected.
The port is connected at 10/100/1000 Mbps.
The port is receiving or transmitting traffic.
The port is not connected.
The port is connected.
The port is receiving or transmitting traffic.
Product Overview
7
