- Page 1 Ruijie RG-NBS5500-12XS Switch Installation Guide Document Version: V1.0 Date: August 28, 2024 Copyright © 2024 Ruijie Networks...
- Page 2 Unless agreed upon otherwise in the contract, Ruijie Networks does not provide any explicit or implicit statements or warranties regarding the content of this document.
-
Page 3: Preface
Preface Intended Audience This document is intended for: Network engineers Technical support and servicing engineers Network administrators Technical Support Ruijie Networks website: https://www.ruijienetworks.com/ Online support center: https://ruijienetworks.com/support Case portal: https://caseportal.ruijienetworks.com Community: https://community.ruijienetworks.com ... - Page 4 Note The manual provides configuration information, including models, port types, and command line interfaces, for reference purposes only. In the event of any discrepancy or inconsistency between the manual and the actual version, the actual version shall take precedence.
-
Page 5: Table Of Contents
Contents Preface ..............................I 1 Introduction ............................1 1.1 Overview ............................ 1 1.2 Package Contents........................1 1.3 Product Appearance ........................ 2 1.3.1 Front Panel ........................2 1.3.2 Rear Panel ........................3 1.4 Technical Specifications ......................4 2 Preparing for Installation ........................6 2.1 Safety Precautions ........................ - Page 6 2.2.8 Surge Protection Requirements................... 10 2.2.9 Installation Site Requirements ..................10 2.3 Rack Requirements ......................... 11 2.4 Tools ............................12 3 Installing the Switch ......................... 13 3.1 Installation Procedure ......................13 3.2 Before You Begin ........................13 3.3 Install the Device in the Specified Location ................14 3.3.1 Precautions ........................
- Page 7 4.2.2 Checklist After Power-on ..................... 18 5 Common Troubleshooting ........................ 19 5.1 Troubleshooting Flowchart ...................... 19 5.2 Troubleshooting ........................19 6 Appendix ............................21 6.1 Appendix A: Ports, Connectors, and Media ................21 6.1.1 1000BASE-T/100BASE-TX/10BASE-T Ports .............. 21 6.1.2 SFP and SFP+ Ports....................22 6.2 Appendix B: SFP and SFP+ Modules ..................
-
Page 8: Introduction
The RG-NBS5500-12XS switch is a high-speed all-optical multi-port core switch launched by Ruijie Networks. It is easy to use, and can be managed by Ruijie Cloud. Its powerful Layer 3 performance and cost-effective 10G optical ports fully meet the service requirements of high-bandwidth data exchange. This switch supports virtual cloud stacking (VCS) and backup. -
Page 9: Product Appearance
Product Appearance The RG-NBS5500-12XS switch provides 12 x SFP+ ports, one 10/100BASE-T RJ45 MGMT port, and one reset button on the front panel. The rear panel provides an AC power connector. The following figures show the product appearance. -
Page 10: Rear Panel
Installation Guide Introduction occurred. Off: No link is established on the port. MGMT port LED Solid green: The port is connected, but no data is being transmitted. Blinking green: The port is connected, and data is being transmitted. Off: No link is established on the port. Optical port status Solid green: The port is working properly at 1/10 Gbps, but no data is being transmitted. -
Page 11: Technical Specifications
Cable Types Caution The supported optical transceiver types may update without prior notification. Contact Ruijie Networks for details. AC input: Rated voltage range: 100 V AC to 240 V AC Max. voltage range: 90 V AC to 264 V AC... - Page 12 The switch has a built-in lithium battery to keep the real-time clock running when external power source is unavailable. To replace the lithium battery, please contact Ruijie Networks Customer Service Technical Support to have it replaced with a lithium battery of the same specifications.
-
Page 13: Preparing For Installation
Installation Guide Preparing for Installation Preparing for Installation Safety Precautions Note To avoid bodily injury and device damage, carefully read the safety precautions before you install the device. The following safety precautions may not cover all possible dangers. 2.1.1 General Safety Precautions ... -
Page 14: Esd Safety
Installation Guide Preparing for Installation the risk of electric shock. A leakage protector should meet the following requirements: ○ The rated leakage action current of each leakage protector is greater than twice of the theoretical maximum leakage current of all the power supplies in the system. For example, if a system is equipped with 16 identical power supplies, and the leakage current of each power supply is equal to or less than 3.5 mA, then the leakage current of the system totals 56 mA. -
Page 15: Installation Environment Requirements
Installation Guide Preparing for Installation Figure 2-1 Laser Product Warning Warning Do not approach or look directly into any optical port under any circumstances. This may cause permanent damage to your eyes. Installation Environment Requirements Install the device indoors to ensure its normal operation and prolonged service life. The installation site must meet the following requirements. -
Page 16: Cleanliness Requirements
Installation Guide Preparing for Installation Note The operating temperature and humidity of the device are measured 1.5 m (59.06 in.) above the floor and 0.4 m (15.75 in.) before the rack when there is no protective plate in front or at the back of the rack. 2.2.5 Cleanliness Requirements Dust poses a major threat to the operational safety of the device. -
Page 17: Anti-Interference Requirements
Installation Guide Preparing for Installation Secure Grounding Ensure that the rack and power distribution device are securely grounded if the device uses the AC power supply. Failure to do so may result in an increased risk of electric shock, particularly when the insulation resistance between the power supply inside the device and the chassis decreases. -
Page 18: Rack Requirements
Installation Guide Preparing for Installation chassis. Maintain a minimum clearance of 150 mm (5.91 in.) around the air outlets for heat dissipation. You are advised to install the device in a standard 19-inch rack, or place it on a clean workbench. In hot areas, air-conditioning is recommended. -
Page 19: Tools
Installation Guide Preparing for Installation Tools Table 2-3 Tools Phillips screwdriver, power cords, Ethernet cables, cage nuts, diagonal pliers, and cable Common Tools ties Special Tools ESD gloves, wire strippers, crimpers, RJ45 connector crimping pliers, and wire cutters Meters Multimeter Relevant PC, display, and keyboard Devices... -
Page 20: Installing The Switch
Installation Guide Installing the Switch Installing the Switch Caution Before installing the device, ensure that all the requirements described in Chapter 2 are met. Installation Procedure Figure 3-1 Installation Flowchart Prepare for installation Install the device in the specified location Connect the grounding cable Connect the power cord Connect the Ethernet cables... -
Page 21: Install The Device In The Specified Location
Installation Guide Installing the Switch Install the Device in the Specified Location 3.3.1 Precautions Pay attention to the following during installation: Connect the power wires of different colors to the corresponding cable terminals. Ensure that the connector of the power cord is properly seated in the power connector of the device. After plugging the power cord into the device, secure the power cord with the power cord retention clip. -
Page 22: Connecting The Grounding Cable
Installation Guide Installing the Switch Figure 3-3 Mounting the Switch to the Rack Figure 3-4 Switch Mounted in the Rack Connecting the Grounding Cable The grounding stud on the rear of the switch should be connected to the grounding lug of the rack, which should be connected to the ground bar in the equipment room. -
Page 23: Connecting Cables
Installation Guide Installing the Switch During device installation, connect the grounding cable first and disconnect it last. The cross-sectional area of a protective grounding cable should be at least 2.5 mm (12 AWG). The sectional area of a grounding cable should be determined by the possible maximum current. Grounding cables with good conductors should be used. -
Page 24: Steps
Installation Guide Installing the Switch 3.6.2 Steps (1) Bind the drooping part of the optical cables and twisted-pair cables, and route them to both sides of the chassis for convenience. (2) On both sides of the chassis, fasten the optical fibers and twisted-pair cables to the cable management ring or cable chute. -
Page 25: Verifying The Operating Status
Installation Guide Verifying the Operating Status Verifying the Operating Status Setting Up the Configuration Environment 4.1.1 Connecting the PC to the Switch Connect one RJ45 connector of the Ethernet cable to the Ethernet port of the PC. Connect the other RJ45 connect of the Ethernet cable to the MGMT port of the switch. 4.1.2 Logging In to the Web Interface (1) Configure your PC with an IP address in the subnet 10.44.77.XXX (1-255, excluding 200). -
Page 26: Common Troubleshooting
The device is not working properly Check the device installation Check the power connection Check the LEDs status of the device Check the cable connection Contact technical support of Ruijie Networks Troubleshooting Fault Symptom Possible Cause Solution The login password... - Page 27 Installation Guide Common Troubleshooting The optical cable type does not Replace the optical cable with a meet requirements. qualified one. The length of the optical cable is Use an optical cable of required beyond the allowed length marked length. on the optical transceiver. The fiber or connector is Clean the end face with a dust-free contaminated.
-
Page 28: Appendix
Installation Guide Appendix Appendix Appendix A: Ports, Connectors, and Media 6.1.1 1000BASE-T/100BASE-TX/10BASE-T Ports The 1000BASE-T/100BASE-TX/10BASE-T port is a 10/100/1000 Mbps auto-negotiation port that supports auto medium-dependent interface/MDI crossover (MDI/MDIX). RJ45 connectors are supported. Compliant with IEEE 802.3ab, the 1000BASE-T port requires 100-ohm Category 5 or Category 5e unshielded twisted pair (UTP) or shielded twisted pair (STP) (recommended) with a maximum distance of 100 meters (328 feet). -
Page 29: Sfp And Sfp+ Ports
Hardware Installation and Reference Guide Appendix 4, 5, 7, 8 Not Used Not Used Figure 6-2 shows wiring of straight-through and crossover cables for the 100BASE-TX/10BASE-T port. Figure 6-2 100BASE-TX/10BASE-T Twisted Pair Connections 6.1.2 SFP and SFP+ Ports SFP and SFP+ ports are also called optical ports, which require optical transceivers or copper SFP transceivers. ... -
Page 30: Appendix B: Sfp And Sfp+ Modules
(Mini-GBIC-GT transceivers) are supported. The following models and technical specifications of some SFP and SFP+ transceivers are provided for your reference. For details about the technical specifications, see Ruijie Optical Module Hardware Installation and Reference Guide . 6.2.1 SFP Modules... - Page 31 Hardware Installation and Reference Guide Appendix Intensity of Intensity of Optical Transmitted Received Light Wavelength Model Cable Light (dBm) (dBm) (nm) (Yes/No) type –9.5 –3 –17 GE-SFP-SX –9.5 –3 –20 –3 GE-SFP-LX 1310 –9.5 –3 –17 SFP-MM850 –9.5 –3 –20 –3 SFP-SM1310 1310...
- Page 32 Hardware Installation and Reference Guide Appendix Core Connector Optical Cable Max. Cabling SFP Model Specifications Type Type Distance (μm) GE-SFP-LH40-SM1550-BIDI 9/125 40 km (131233.60 ft) MINI-GBIC-ZX50-SM1550 9/125 50 km (164042 ft) MINI-GBIC-ZX80-SM1550 9/125 80 km (262467.19 ft) 100 km (328083.99 MINI-GBIC-ZX100-SM1550 9/125 62.5/125...
-
Page 33: Sfp+ Modules
Hardware Installation and Reference Guide Appendix 6.2.2 SFP+ Modules Table 6-6 Models and Specifications of SFP+ Modules Intensity of Intensity of Optical Transmitted Light Received Light Wavelength Cable Model (dBm) (dBm) (nm) (Yes/No) Type XG-SFP-SR- –7.3 –1 –9.9 –1 MM850 –7.3 –1 –9.9... - Page 34 SFP+ transceiver types are subject to change without prior notice. For more accurate information about the optical transceivers, contact Ruijie marketing or technical support personnel. The DDM function of AOC cables does not report the transmit power. The TX power is displayed as N/A.
- Page 35 Hardware Installation and Reference Guide Appendix Modal Optical Core Connector Max. Cabling Bandwidth Cable Model Specifications Distance Type (μm) (MHz·km) Type XG-SFP-LR-SM1330- 10 km 9/125 BIDI (32,808.40 ft) 10 km XG-SFP-LR-SM1310 9/125 (32,808.40 ft) 40 km XG-SFP-ER-SM1550 9/125 (131,233.60 ft) 80 km XG-SFP-ZR-SM1550 9/125...
-
Page 36: Appendix C: Lightning Protection
Installation Guide Appendix Appendix C: Lightning Protection 6.3.1 Installing an AC Power Arrester (Lightning Resistance Socket) When an AC power cord is introduced from outdoors and directly connected to the power port of the device, the AC power port must be connected to an external lightning protection power strip to protect the device against lightning strokes. -
Page 37: Installing The Ethernet Port Arrester
Hardware Installation and Reference Guide Appendix left and the L line is on the right (facing the socket), the arrester's PE terminal is not grounded. If not, the polarity of the arrester power cord should be reversed. In this case, you should open the power arrester and rectify the polarity of the connection. - Page 38 Hardware Installation and Reference Guide Appendix Pay attention to the following situations during the installation to avoid influencing the performance of the Ethernet port arrester: Reversed installation direction of the arrester. Connect the external network cable to the "IN" end and connect the Ethernet port of the device to the "OUT"...
-
Page 39: Appendix D: Cabling Recommendations
Installation Guide Appendix Appendix D: Cabling Recommendations When the device is installed in a standard 19-inch rack, secure the cables around the cable management brackets. Adopt top cabling or bottom cabling according to the actual situation in the equipment room. All cable connectors used for transit should be placed at the bottom of the cabinet rather than be exposed outside of the cabinet. - Page 40 Hardware Installation and Reference Guide Appendix Figure 6-6 Binding Cables (I) Cables of different types (such as power cords, signal cables, and ground cables) should be separated in cabling and bundling. Mixed bundling is disallowed. When they are close to each other, you are advised to adopt crossover cabling.
- Page 41 Hardware Installation and Reference Guide Appendix When cables need to be bent, please bundle them up but do not tie them where the cables will be bent, as shown in Figure 6-8. Figure 6-8 Binding Cables (III) Cables not to be assembled or remaining parts of cables should be folded and placed in a proper position of the rack or cable trough.
- Page 42 Hardware Installation and Reference Guide Appendix Nut Flat washer Hard power cords should be fastened in the terminal connection area to prevent stress on terminal connection and cable. Do not use self-tapping screws to fasten terminals. ...
-
Page 43: Appendix E: Equipment Room Site Selection
Installation Guide Appendix Appendix E: Equipment Room Site Selection The equipment room should be at least 5 km (3.11 miles) away from heavy pollution sources, such as the smelter works, coal mine, and thermal power plant. The equipment room should be at least 3.7 km (2.30 miles) away from medium pollution sources, such as the chemical factory, rubber factory, and electroplating factory.
