Dell PowerVault
130T Library
USER'S GUIDE
www.dell.com

Advertisement

Table of Contents
loading

Related Manuals for Dell PowerVault 130T

Summary of Contents for Dell PowerVault 130T

  • Page 1 ® ™ Dell PowerVault 130T Library USER’S GUIDE www.dell.com...
  • Page 3 ® ™ Dell PowerVault 130T Library USER’S GUIDE www.dell.com...
  • Page 4 Reproduction in any manner whatsoever without the written permission of Dell Computer Corporation is strictly forbidden. Trademarks used in this text: Dell, the DELL logo are registered trademarks, and PowerVault is a trademark of Dell Computer Corporation. Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products.

  • Page 5: About This Guide

    Preface About This Guide This guide is intended for anyone who uses a PowerVault 130T . The guide provides instruction on how to install and operate a PowerVault 130T. This User’s Guide is organized as follows: • Chapter 1,“Equipment Description,” explains the basic configuration of the PowerVault 130T , its features, and major components.

  • Page 6: Other Documents You May Need

    The names of various light-emitting diodes (LEDs) are shown in italics, normal font. Ordering Publications To order publications contact your Dell sales/marketing representative or go to our Web Site at www.dell.com. User’s Guide...

  • Page 7: Safety Warnings

    Ventilation- Place the library in a location or position that does not interfere with proper ventilation. • Heat- Place the PowerVault 130T in a location away from heat sources such as radiators, heat registers, furnaces, or other heat producing appliances. •...

  • Page 8: Safety Guidelines

    • Place the PowerVault 130T on a level surface. Make sure that the surface is free from vibration. Do not place anything on top of the unit. Safety Guidelines On-the-job safety is important;...

  • Page 9: Protecting Against Electrostatic Discharge

    • Place your feet 31–46 centimeters (12–18 inches) apart—approximately shoulder width—and place one foot a little behind the other. Keep your back straight, because even light loads can significantly increase pressure on the spine when you lean forward. • Whenever possible use two hands and grip the load with your whole hand. •...

  • Page 10: Power Requirements

    Power Requirements The PowerVault 130T uses a 115V or a 230V Power Cord. To help prevent damage to your system be sure to use the power cord that matches the power available in your area. • 115 V/60 hertz (Hz) in most of North and South America and some Far Eastern countries such as Japan, South Korean, and Taiwan.

  • Page 11: Table Of Contents

    Description of the PowerVault 130T Library ........1-2...
  • Page 12 Removing a Cartridge from the Hand........3-18 Removing/Replacing a Cartridge in the Storage Cells ..... . .3-20 Mounting a Cartridge into a Drive .
  • Page 13 PowerVault 130T Library Operator Panel ........
  • Page 14 PowerVault 130T Major Components ........

  • Page 15: Equipment Description

    The PowerVault 130T is a self-contained, fully automated cartridge system that can accommodate up to four digital linear tape (DLT) drives. The PowerVault 130T uses a small computer system interface (SCSI) library command set and attaches directly to the SCSI bus.

  • Page 16: Description Of The Powervault 130T Library

    Viewing Window Cartridge Access Port (CAP) Key Lock - safety interlock switch Front Door Operator Panel Description of the PowerVault 130T Library The major PowerVault 130T internal components are shown: Figure 1-2. Major Components Major Components Item Parts Description Number...
  • Page 17 Removable Five-Cell Cartridge Magazine A removable five-cell cartridge magazine is included with the PowerVault 130T . This can be easily taken out, loaded with batch jobs or special applications, and replaced in the library whenever it is required.
  • Page 18 Storage Cells The PowerVault 130T contains storage cells for 28 to 30 CompacTape IV tape cartridges. CompacTape III and IIIXT are also supported, although they have a lesser capacity. With four drives installed, 28 cartridges is the maximum.

  • Page 19: Storage Cell Locations

    Figure 1-3. Storage Cell Locations Storage Cell Location (Front View of the PowerVault) Item Parts Description Number Drive Slot 3 Drive Slot 2 Drive Slot 1 Drive Slot 0 NOTE: If a drive is not installed in slot 3, two additional storage cells must be installed there.

  • Page 20: Operator Panel

    The host software then allocates a tape drive to receive the cartridge for read/write operations. Power Switch The power switch for the PowerVault 130T is located on the upper right rear of the unit, as shown in Figure 1-4. User’s Guide...
  • Page 21 Figure 1-4. Rear View Showing Power Switch Rear View Showing the Power Switch Item Parts Description Number Power Switch Equipment Description...
  • Page 22 User’s Guide...

  • Page 23: Unpacking And Installation

    Rear; 20.5 cm (8 in.) operating minimum 61 cm (24 in.) minimum for servicing Be sure the location has adequate AC power. If you have a pedestal PowerVault 130T , place it in a location where there is adequate air flow behind and around your PowerVault 130T . Follow the guidelines above.

  • Page 24: Rack Guidelines

    Rack Guidelines If you are installing one or more PowerVault 130T in a rack, be sure the following rack requirements (for up to three libraries) are met: • Rack width - standard 48.3 cm (19 in.) • Rack height - 172.7 cm (68 in.) •...

  • Page 25: Exterior Packing Of The Library

    Figure 2-1. Exterior Packing of the Library Unpacking and Installation...

  • Page 26: Unpacking The Powervault 130T Interior

    Plastic Bag Banding (2x) Unpacking the PowerVault 130T Interior To unpack the interior of the PowerVault 130T Open the front door. Using a diagonal wire cutter, cut and discard the two tie wraps that hold the hand assembly cushion and the counterweight cushion. Figure 2-2 shows the locations of the tie wraps and cushions.

  • Page 27: Interior Packing Of The Library

    Figure 2-2. Interior Packing of the Library Interior Packing of the Library Item Part Description Number Counterweight Counterweight Cushion Tie Wrap Hand/Camera Assembly Hand/Camera Assembly Cushion Tie Wrap Shaded Area - Foam Packing Cushion Unpacking and Installation...

  • Page 28: Inspecting The Powervault 130T

    Open the hinged access door. Look inside the PowerVault 130T for broken or loose parts. Use a flashlight if necessary. Verify that the serial number of the PowerVault 130T (located on the rear panel) matches the shipping invoice.
  • Page 29 Connect one end of the Library to Drive SCSI cable to drive 0 and the other end of the cable to the SCSI port on the library electronics module. Refer to Figure 2-3. Connect a SCSI daisy-chain cable from drive 0 to drive 1. Install the SCSI terminator on the remaining SCSI connector of the last drive.

  • Page 30: Example Of External Scsi Cabling- 2 And 4 Drive Configurations

    Figure 2-3. Rear View of the PowerVault 130T-Example of External SCSI Cabling 2 and 4 drive Configurations User’s Guide...

  • Page 31: Connecting The External Ac Power Cable

    Plug the male end of the AC power cable into the AC power source. When connecting to AC power sources with non-US AC power connectors, it may be necessary to replace the power plug to suit local standards. This should be done by a qualified Dell service technician. Unpacking and Installation...

  • Page 32: Location Of Ac Power Receptacle

    Figure 2-4. Location of AC Power Receptacle Location of AC Power Receptacle Item Parts Description Number AC Power Receptacle 2-10 User’s Guide...

  • Page 33: Preparing The Library For Use

    Completing the installation of the library Installing the Cartridge Tapes in the Library The library has storage cells for 30 cartridge tapes unless four drives are installed, which reduces the number to 28. Five of the storage cells are contained in a removable magazine.
  • Page 34 VOLSER label facing out. Figure 2-6 shows the orientation of the cartridge tape for installation. Refer to Chapter 4 for instructions on how to apply the cartridge label. Slide each cartridge tape into the storage cell until the cartridge stops and catches on the retaining boss. Close the front door.

  • Page 35: Powering On The Powervault 130T

    Cartridge Tape Storage Cell Cartridge Tape Volser Label Powering On the PowerVault 130T Library The power switch for the PowerVault 130T is located on the upper right rear of the unit, as shown in Figure 2-7. Unpacking and Installation 2-13...

  • Page 36: Completing The Installation Of The Library

    PowerVault 130T Power Switch Power Switch When the PowerVault 130T is powered on or reset, it performs a complete diagnostic routine and a tape audit. If the front door is opened and closed while power is on, the library performs the same routines (except realigning to the cells). During these operations, the library displays its current activity on the operator panel display.

  • Page 37: Operating The Powervault 130T

    C H A P T E R 3 Operating the PowerVault 130T The PowerVault 130T Library operator panel includes a four-line 20-character per line, backlit display for viewing library and DLT drive status. The operator panel also includes five function buttons and three light-emitting diodes (LEDs). The function buttons allow access to all of the menus, status displays, machine diagnostics, and error information available for the DLT Library.

  • Page 38: Operator Panel Controls

    PowerVault 130T Operator Panel Item Part Description Number Operator Panel Display Light-Emitting Diodes (LEDs) Function Buttons SYSTEM RESET ENTER button MENU button Library Active LED Cartridge Access Port (CAP) Open LED Service Required LED Operator Panel Controls The operator panel has five function buttons.

  • Page 39: Menus And Displays

    Check the Status Display for indication of the problem. Menus and Displays The hierarchy of menus in the PowerVault 130T Library is shown in Figure 3-2. Figure 3-2. Operator Panel Menu Flow Chart To select an item, move the cursor using the up or down arrows until it points to the item, and press ENTER.

  • Page 40: Main Menu

    Main Menu > Status Display Library Utilities Drive Utilities Main Menu Options Option Status Display Library Utilities Drive Utilities Status Display The first line of the Status Display (the library status line) shows the state of the CAP . The normal CAP states are: CAP States State CAP Locked, No Entry...
  • Page 41 NOTE: If the library contains four DLT drives (the fourth in slot 3 at the top), you can see the status of the fourth drive by pressing the up arrow on the operator panel to allow the drive status lines to scroll. Line 1 Line 2 Line 3 Line 4 Operating the PowerVault 130T...

  • Page 42: Library Utilities

    Library Utilities The Library Utilities menu displays diagnostic, error, and configuration items. > Library Diags Examine FSCs View Configuration Set Configuration Library Utilities Utility Library Diags Examine FSCs View Configuration Set Configuration Library Diagnostics The Library Diagnostics menu displays library diagnostic options. >...
  • Page 43 The library provides detailed prompts for running the diagnostic routines (including specifying drives for mounts and dismounts). Select the desired routine using the arrow buttons, and press ENTER. Then follow the prompts given on the operator panel display. Operating the PowerVault 130T...

  • Page 44: Examine Fault Symptom Codes (Fscs)

    Examine Fault Symptom Codes Fault Symptom Codes (FSCs) are four hexadecimal digits that identify an error in the system. The Examine FSCs menu option allows the operator to view the last 20 fault symptom codes. Use the arrow buttons to scroll the lines of the display. An example of the FSC display is shown below.

  • Page 45: Set Configuration

    “off-lib bus” (a different bus). The on-lib bus or off-lib bus setting applies to the status of a tape drive inside the Dell PowerVault 130T . A tape on the library bus (on lib bus) shares the same SCSI chain as the library port.
  • Page 46 Option Set Fast Load Set Auto Clean Set Cart Magazine Set SCSI Emulation The library provides detailed prompts for setting the configuration. Select the desired configuration option using the arrow keys, and press ENTER. Then follow the prompts given on the Operator Panel display. (Some of the above selections post an information screen before the entry screen.

  • Page 47: Drive Utilities

    Drive 0 is on the library bus and Drive 1 is off the library bus. Item Part Description Number Library Ports SCSI Chain 1 Terminator SCSI Chain 2 Drive 1 Drive 0 Drive Utilities Drive Utilities displays tape drive utility options. Operating the PowerVault 130T 3-11...

  • Page 48: Using The Removable Cartridge Magazine

    The five-cell cartridge magazine included in the PowerVault 130T Library can be loaded with batch jobs, such as payroll or other special applications, and removed from or replaced in the library as needed.

  • Page 49: Replacing The Five-Cell Cartridge Magazine

    Figure 3-5. Replacing the Five-Cell Cartridge Magazine Replacing the Five-Cell Cartridge Magazine Item Part Description Number Receiver Unit 5 Cartridge Magazine Operating the PowerVault 130T 3-13...

  • Page 50: Manual Operations

    Mounting/dismounting a cartridge to a drive. Inserting a Cartridge into the Cartridge Access Port While the PowerVault 130T Library is operating in automated mode, the robot mounts and dismounts cartridges to the DLT drives automatically on request from the host software.

  • Page 51: Removing A Cartridge From The Cartridge Access Port (Cap)

    “ Clean Me ” message to the operator panel. When you need to clean a drive do the following: Select “ Clean a Drive ” from the Drive Utilities menu, shown below. Operating the PowerVault 130T 3-15...

  • Page 52: Moving The Hand/Camera Assembly Manually

    If the library robot fails to operate and you want to mount a tape into a drive, the hand/ camera assembly might be in the way of the cartridge tape you want to reach, whether that tape is in a DLT drive or a storage cell. Figure 3-7. Moving the Hand/Camera Assembly 3-16 User’s Guide...

  • Page 53: Retracting The Picker Assembly

    CAUTION: Make sure the picker assembly, shown in Figure 3-8, is retracted before moving the hand, to prevent it from striking the storage cells. Push it back with your finger.

  • Page 54: Removing A Cartridge From The Hand

    Push the cartridge the rest of the way into the Cartridge Access Port (CAP) or empty storage cell. Rotate the robot/hand until it is moved out of the way. Remove the cartridge from the Cartridge Access Port (CAP) or empty storage cell, if needed. 3-18...

  • Page 55: Removing A Cartridge From The Hand

    Figure 3-9. Removing a Cartridge from the Hand Operating the PowerVault 130T 3-19...

  • Page 56: Removing/Replacing A Cartridge In The Storage Cells

    Spring-Loaded Push Fingers (2x) Tape Cartridge Removing/Replacing a Cartridge in the Storage Cells Figure 3-10 shows the storage cell locations in the library. When you locate the cartridge tape you need, pull it straight out of the cell. Figure 3-10. Storage Cell Locations...
  • Page 57 In this figure, the number in parentheses equals the total cartridge count. The other number is the storage cell number in one of the three columns. The storage cell layout as a whole is called the “array.” The “array targets” are used for robotic calibration during initialization.

  • Page 58: Mounting A Cartridge Into A Drive

    Cartridge Tape Volser Label When manually placing cartridge tapes in storage cells, be sure the cartridge is right side up (writing on top) with the VOLSER label facing out, as shown in Figure 3-11. Mounting a Cartridge into a Drive To manually mount a cartridge tape into a DLT drive, the load latch must be UP , which indicates the drive is open.

  • Page 59: Dlt Drive Closed/Open

    Light Emitting Diode (LED) (shown in Figure 3-14) on the drive face solid on (not flashing). The latch has a breakaway feature to prevent damage. If it breaks away, return it to one of the positions shown in figure 3-12. Figure 3-12. DLT Drive Closed/Open Operating the PowerVault 130T 3-23...
  • Page 60 DLT Drive Closed/Open Item Parts Description Number Drive Open (Load Latch Up) Load Latch Operate Handle Light Emitting Diode (LED) Drive Hub Retracted Drive Closed (Load Latch Down) Breakaway Feature Load Latch Drive Hub Extended NOTE: For clarity, the drives are shown out of the library with no tapes loaded.

  • Page 61: Dismounting A Cartridge From A Drive

    Lift the load latch and the tape will eject. Remove the cartridge. DLT Drive Light Emitting Diodes (LEDs) The right side Light Emitting Diodes (LEDs) on the DLT drive face are shown in Figure 3-14 and explained in Table 3-1. Operating the PowerVault 130T 3-25...

  • Page 62: Dlt Drive Light Emitting Diodes (Leds)

    Figure 3-14. DLT Drive Light Emitting Diodes (LEDs) DLT Drive Light Emitting Diodes (LEDs) Item Number Parts Description Description of the DLT4000 Tape Drive Status/Control Panel DLT4000 Tape Drive Status/Control Panel Write Protected Tape In Use Use Cleaning Tape 3-26 User’s Guide...
  • Page 63 Density Override Compress 20.0 10.0 Description of the DLT7000 Tape Drive Status/Control Panel DLT7000 Tape Drive Status/Control Panel Write Protected Tape In Use Use Cleaning Tape Operate Handle Unload Select Density Override Compress 35.0 20.0 10.0/15.0 Operating the PowerVault 130T 3-27...
  • Page 64 Table 3-1. DLT Drive LEDs (right front panel) Label Color Write Protected Orange Tape in Use Yellow Use Cleaning Tape Yellow Operate Handle Green The Light Emitting Diodes on the left front face of the DLT drives are yellow and indicate the tape format.

  • Page 65: Handling Cartridge Tapes

    Keep cartridges clean. • Inspect cartridges before each use. • Never put a damaged cartridge into a drive or storage cell. • Do not open cartridges or release the cartridge latch and pull out tape. • Do not handle tape that is outside the cartridge.

  • Page 66: Applying Cartridge Labels

    Back Side Applying Cartridge Labels The PowerVault 130T Library uses CompacTape IV (DLTtape) cartridge tapes for data, plus diagnostic and cleaning cartridges. (CompacTape III and IIIXT (DLTtape) are also supported.) Different types of data cartridge are distinguished by a small letter next to the last number in the VOLSER.

  • Page 67: Setting Cartridge Write Protection

    NOTE: Diagnostic cartridges are physically the same as data cartridges. The library requires the “DG” label before it will use a cartridge for diagnostic routines. One diagnostic label is supplied with the PowerVault 130T Library. Figure 4-2. Applying Cartridge Labels...

  • Page 68: Storing Cartridges

    Leave cartridges in their protective wrapping. (When using a cartridge, remove its wrapping using the tear string, not sharp instruments.) • Make sure the storage environment is clean and conditions equivalent to the PowerVault 130T operating environment. • Before using tapes, keep them in their operating environment for 24 hours.

  • Page 69: Dlt Drive Tray Assembly

    C H A P T E R 5 DLT Drive Tray Assembly The tape drives are located in the tape drive slots at the left rear of the library. NOTE: Tape drives are hot swappable, meaning they can be removed and replaced without powering off the library or interrupting its operations.
  • Page 70 Figure 5-1. Back View of Drive Tray Assembly Back View of Drive Tray Assembly Item Parts Description Number Tape Drive Thumbscrew (3x) Hinged Door User’s Guide...

  • Page 71: Interface Connection And Power

    Figure 5-2. Interface Connection and Power Interface Connection and Power Item Parts Description Number Tape Drive Interface Connector Power Receptacle Thumbscrew (3x) Disconnect the power cable from the tape drive. CAUTION: Disconnect the tape drive interface cable (P980-P983), as described in the next step, before removing the tape drive.

  • Page 72: Replacing The Tape Drive Tray Assembly

    • Verify that required cables are present. • Report any damaged or missing items to your Dell representative. WARNING: Do not touch any components on the power supply. Live voltage could be present even though the unit is powered off.
  • Page 73 Setting TermPwr Item Parts Description Number Power Supply Cover Power Supply Cover Screw Location (2x) TermPwr Jumper, second pair of pins from end of connector (shown enabled) To check terminator power (TERMPWR), remove the two power supply cover screws using a Torx driver with a T-15 bit, and lift the cover (pulling forward slightly) enough to see the jumpers.

  • Page 74: Connecting The Scsi Cable

    Figure 5-4. Connecting the SCSI cable Connecting the SCSI cable Item Parts Description Number Tape Drive Interface Cable (P983) Thumbscrew (2x) SCSI Connector (2x Per Drive) Drive 0 CAUTION: The tape drive interface cable (P980-P983) marking faces the rear of the tape drive.
  • Page 75 Close the hinged door at the rear of the library. 10. Tighten the three thumbscrews to secure the door. 11. Connect the SCSI cables and/or terminator to the SCSI connectors on the rear of the tape drive. DLT Drive Tray Assembly...
  • Page 76 User’s Guide...

  • Page 77: Supporting Information

    A P P E N D I X Supporting Information This appendix lists the specifications for the PowerVault 130T Library. Specifications Table A-1 through Table A-6 detail PowerVault 130T Library specifications. Table A-1. Functional Data Item Media Number of cartridge cells...

  • Page 78: Physical Specifications

    Table A-2. Reliability Item Mean exchanges between failures (MEBF) Mean time to repair (MTTR) Table A-3. Physical Specifications Item Width Height Depth Rear clearance, library to any wall or other cabinet Front clearance, library to any wall or other cabinet Minimum clearance required to remove/replace electronics module or tape drive Weight with no drives...

  • Page 79: Environmental Specifications

    Korean EMC Law BCIQ EMC Law CNS 13438 (Taiwan) Immunity European Union CE immunity standards AS/NZS 4252.1: 1994 Generic Immunity Standard Measurement Operating Storage +15 to +32ºC +10 to +40ºC +59 to +90ºF +50 to +104ºF 20 to 90% 10 to 95% +29.2ºC...
  • Page 80  ...

  • Page 81: Appendix B Regulatory Notices

    Plug the computer into a different outlet so that the computer and the receiver are on different branch circuits. If necessary, consult a Regulatory EMC representative of Dell Computer Corporation or an experienced radio/television technician for additional suggestions. You may find the FCC Interference Handbook, 1986, to be helpful.

  • Page 82: Fcc Notices (U.s. Only

    Using shielded cables ensures that you maintain the appropriate EMC classification for the intended environment. For parallel printers, a cable is available from Dell Computer Corporation. If you prefer, you can order a cable from Dell Computer Corporation on the World Wide Web at http://www.dell.com/products/dellware/ index.htm.

  • Page 83: Ic Notice (Canada Only

    IC Notice (Canada Only) Industry Canada regulations provide that changes or modifications not expressly approved by Dell Computer Corporation could void your authority to operate this equipment. This Class B (or Class A, if so indicated on the registration label) digital apparatus meets the requirements of the Canadian Interference-Causing Equipment Regulations.

  • Page 84: Vcci Notice (Japan Only

    VCCI Notice (Japan Only) The following is the compliance statement for Japan. This is a Class A product based on the standard of the Voluntary Control Council for Interference (VCCI) for information technology equipment. If this equipment is used in a domestic environment, radio disturbance may arise.

  • Page 85: Warranties And Return Policy

    (except as specifically noted); accessories or parts added to a Dell system after the system is shipped from Dell; accessories and parts added to a Dell system through Dell’s system integration department; accessories or parts that are not installed in the Dell factory;...

  • Page 86: Coverage During Years Two And Three

    NOTE: Before you ship the product(s) to Dell, back up data on any hard-disk drive(s) and any other storage device(s) in the product(s). Remove any removable media. Dell does not accept liability for lost data or software. Dell owns all parts removed form repaired products. Dell uses new and reconditioned parts made by various manufacturers in performing warranty repairs and building replacement products.

  • Page 87: Total Satisfaction" Return Policy (U.s. And Canada Only

    If you are an end-user customer who bought products directly form a Dell company, you may return them to Dell up to 30 days from the date of invoice for a refund of the product purchase price if already paid. This refund will not include any shipping and handling charges shown on your invoice.
  • Page 88    ...

  • Page 89: Internal Code License Agreement

    Please read this notice carefully before installing and operating this equipment. This notice is a legal agreement between you (either an individual or an entity), the End User, and Dell Corporation (“Dell”), The Manufacturer the equipment. By opening the package and accepting and using any unit of equipment described in this document, you agree to become bound by the terms of this agreement.
  • Page 90   ...
  • Page 91 Audit- An operation performed by the PowerVault 130T Library to track VOLSERs and cartridge locations. Auto Clean- A feature of the PowerVault 130T Library allowing a cleaning cartridge to be kept in a storage cell and accessed automatically when drives need cleaning. (Must also be supported by the host software.)
  • Page 92 To remove a cartridge from a drive. DLT- Digital Linear Tape. DLT drive- A tape drive used in the PowerVault 130T Library in two models DLT4000 and DLT7000. Drive Utilities Menu- The PowerVault 130T menu offering drive utility selections.

  • Page 93: Powervault 130T Operator Panel

    DLT drives for mounting and dismounting cartridge tapes. m- Meter. Main menu- The top-level menu on the PowerVault 130T operator panel display. menus- A hierarchical list of selections on the PowerVault 130T operator panel, providing the user interface to the library. mm- Millimeter.
  • Page 94 An initialization and diagnostic routine performed automatically by the library when it is powered on or reset. status display- A screen on the PowerVault 130T operator panel showing library and drive status. storage cells- The slots where cartridge tapes are kept in the library.
  • Page 95 Index AC power, 2-1 AC power cable external connecting, 2-9 agency certifications, A-3 cable external AC power connecting, 2-9 external SCSI connecting, 2-6 Cartridge Access Port states, 3-5 cartridge access port, 1-4 states, 3-5 cartridge labels, 4-2 cartridge magazine, set, 3-11 cartridge tapes number of, 2-11 cartridge tapes, handling, 4-1...
  • Page 96 drive count, 3-10 drive SCSI ID, 3-10 Fast Load, 3-10 library SCSI ID, 3-10 set, 3-10 view, 3-9 connecting the external AC power cable, 2-9 the external SCSI cables, 2-6 controlling (host) software, 1-6 counterweight cushion, 2-4 cushion counterweight, 2-4 hand assembly, 2-4 date and time, set, 3-10 diagnostics, library, 3-7...
  • Page 97 Fast Load, set, 3-10 fault symptom codes, 3-9 FCC notice, vi features, PowerVault 130T library, 1-2 front view, library, 1-1 Field Replaceable Units (FRUs) DLT drive tray assembly, 5-1 functional specifications, A-1 hand assembly cushion, 2-4 hand/camera assembly, 1-4 host (controlling) software, 1-6...
  • Page 98 1-4 robot, 1-3 hand/camera assembly, 1-4 theta motor, 1-3 Z column assembly, 1-3 Z motor, 1-3 storage cells, 1-4 speed loader, 1-4 library features, 1-2 library menus, 3-4 library operator panel, 3-1 library utilities, 3-7 lifting techniques, viii...
  • Page 99 operator panel, 3-1 controls, 3-2 function buttons, 3-1 LEDs, 3-3 part numbers publications, v physical specifications, A-2 power AC, 2-1 power specifications, A-2 power switch, 1-7, 2-14 powering-on the library, 1-6, 2-13 precautions safety, viii preparing the site, 2-1 procedures selecting menu items, 3-4 using function buttons, 3-4 rack guidelines, 2-2...
  • Page 100 A-2 power, A-2 reliability, A-2 speed loader, 1-4 status display, 3-5 status messages, 3-5 storage cell locations, 1-5, 2-11 storage cells, 1-4 SYSTEM RESET button, 3-3 Taiwan warning statement, B-2 theta motor, 1-3 tools required for installation, 2-2 Index 6...
  • Page 101 unpacking the library exterior, 2-2 interior, 2-4 utilities drive, 3-11 library, 3-7 view configuration, 3-9 volume serial number (VOLSER) labels, 2-12 write protection, cartridge, 4-3 Z column assembly, 1-3 Z motor, 1-3 Index 7...
  • Page 102 Index 8 User’s Guide...
  • Page 104 Printed in the U.S.A. ® 2473D...
