MINI BRUTUS SWINGSET
MANUFACTURED BY:
Backyard Discovery
3305 Airport Drive
Pittsburg, KS 66762
Model # 2051164
Owner's Manual & Assembly Instructions
800-856-4445
average 2 person assembly time
assembly time may vary based on skill level
For the most up to date assembly manual,
to register your set, or to order replacement parts please visit
www.backyarddiscovery.com
SAVE THIS ASSEMBLY MANUAL FOR FUTURE REFERENCE IN THE EVENT THAT
YOU NEED TO ORDER REPLACEMENT PARTS.
Made in China INS-2051164-A-MINI BRUTUS-ENG 3-2-20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MINI BRUTUS and is the answer not in the manual?

Questions and answers

Related Manuals for Backyard Discovery MINI BRUTUS

Summary of Contents for Backyard Discovery MINI BRUTUS

  • Page 1 For the most up to date assembly manual, to register your set, or to order replacement parts please visit www.backyarddiscovery.com SAVE THIS ASSEMBLY MANUAL FOR FUTURE REFERENCE IN THE EVENT THAT YOU NEED TO ORDER REPLACEMENT PARTS. Made in China INS-2051164-A-MINI BRUTUS-ENG 3-2-20...
  • Page 2 INSTALLATION SERVICES AVAILABLE! Need a helping hand? Let our team of professionals handle the installation for you! *Installation services are only available to U.S. customers. With Go Configure, we bring you 18 years of experience right to your doorstep. We service a wide array of indoor and outdoor recreation products that most consumers don’t have the time or ability to deliver &...
  • Page 3 Owner’s Manual Please Read This Before Starting Assembly MISSING A PART? CALL US BEFORE GOING BACK TO THE STORE Th e store where you made your purchase does not stock parts for this item. If you have assembly questions or you are missing or have damaged parts, please call 1-800-856-4445 you can also visit www.backyarddiscovery.com...
  • Page 4 Botanical, Adventure Playsets, and Leisure Time Products. Backyard Discovery warrants that this product is free from defect in materials and workmanship for a period of one (1) year from the original date of purchase. Th is one (1) year warranty covers all parts including wood, hardware, and accessories. All wood carries a fi ve (5) year pro-rated warranty against rot and decay. Refer to the schedule below for charges associated with replacement of parts under this Limited Warranty.
  • Page 5 Owner’s Manual Operating Instructions and Safety Warnings WARNING: BURN HAZARD • Pay special attention to plastic and metal surfaces as they may be hot enough to cause burns. • Always check the temperature of the product before NOTE: letting your children play on it. •...
  • Page 6 Owner’s Manual Please Read This Before Starting Assembly Positioning Your Playcenter Suggested Playground Surfacing • Th e playcenter is designed to be installed on a level • Do not install home playground equipment over surface by an adult with an adult helper. Place concrete, asphalt, packed earth, grass, carpet, or any in a fl at area of your yard to minimize ground other hard surface.
  • Page 7 Owner’s Manual Please Read This Before Starting Assembly APPENDIX A The following information is from the United States X3.1.3.2 Do not install loose-fi ll surfacing over hard surfaces such as concrete or asphalt. Consumer Product Safety Commission’s Information X3.1.4 Poured-In-Place Surfaces or Pre-Manufactured Sheet for playground surfacing material;...
  • Page 8 • Check all moving parts including swing seats, Backyard Discovery assumes no responsibility or ropes, cables, and chains for wear, rust, or other liability for any charge incurred by the Customer for deterioration.
  • Page 9 Owner’s Manual Assembly Tips Protrusion Hazard Incorrect Correct If you see exposed threads and your bolt protrudes beyond the T-Nut you may have over tightened the bolt or used incorrect hardware. If you’ve overtightened, remove the bolt and add washers to eliminate the protrusion.

  • Page 10: Assembly Tip

    Owner’s Manual Assembly Tips ASSEMBLY TIP: Keep an eye out for these boxes which will contain helpful pictures and information making the assembly process as quick and painless as possible. Sorting Hardware NUT BARREL SCREW T-NUT WASHER FLAT BOLT HEX BOLT SCREW PWH H100545...

  • Page 11: Tools Required For Installation

    Tools Required for Installation Owner's Manual Icons and their uses you will see throughout this manual You will need to make sure that your When you see this icon you assembly is square before tightening will need a socket wrench. your bolts.
  • Page 12 Basic Setup Dimensions & Assembly Notes Owner's Manual Selecting the correct location for your play product is improtant for your children's safety and the product's longevity. • The safe play area refers to a zone extending 6 ft 7 in. beyond the play product, including the space above the play product.

  • Page 13: Parts Identification

    Hardware Components Parts Identification H100366 BOLT WH WZ (x4) 5/16x4 H100811 BOLT CARRIAGE WZ (x6) 5/16x2 3/4 H100591 BOLT CARRIAGE WZ (x12) 5/16x2 1/2 H100818 BOLT HEX WZ (x4) M12x 45mm H100499 NUT BARREL WH WZ (x22) 5/16x7/8 H100819 LOCK NUT WZ H100278 WASHER FLAT WZ (x4)
  • Page 14 Accessories (Not to Scale) Parts Identification A4M01013 BOTTOM LEG (x4) A4M01015 TOP LEG (x4) A4M01018 SIDE BAR (x2) A4M01019 A4M01024 METAL BRACKET GREY A4M01020 METAL BRACKET GREEN (x8) LEG CONNECTING TUBE (x2) (x4) A4M01021 SIDE TOP BEAM (x2) A4M01022 TOP BEAM CONNECTING TUBE (x1)
  • Page 15 Accessories (Not to Scale) Parts Identification A6P00435 WARNING LABEL STICKER (x1) A6P00375 BYD TAG STICKER (SMALL) (x1) A6P00366 SWING SET FOOT (x4) A4M01040 H100242 DUCTILE HANGER WZ QUICK LINK (LONG) WZ (x4) (x8) A4M01136 CHAIN GREEN 48.25" (x4) A6P00362 26" HD BELT SWING (x2) A100178 AUGER GROUND STAKE...
  • Page 16 STEP 1 H100591 BOLT CARRIAGE WZ (x4) 5/16x2 1/2 A4M01020 LEG CONNECTING TUBE (x4) A4M01013 BOTTOM LEG (x4) H100811 BOLT CARRIAGE WZ (x4) 5/16x2 3/4 A4M01015 TOP LEG (x4) A4M01019 H100499 NUT BARREL WH WZ METAL BRACKET GREY (x8) (x8) 5/16x7/8 NOTE: REPEAT THIS STEP 4 TIMES.
  • Page 17 STEP 2 A4M01022 TOP BEAM CONNECTING TUBE (x1) H100811 BOLT CARRIAGE WZ (x2) 5/16x2 3/4 A4M01021 SIDE TOP BEAM (x2) H100818 BOLT HEX WZ A4M01040 (x4) M12x 45mm DUCTILE HANGER WZ (x4) H100499 NUT BARREL WH WZ H100242 QUICK LINK (LONG) WZ (x2) 5/16x7/8 (x4)
  • Page 18 STEP 3 A6P00435 WARNING LABEL STICKER (x1) H100591 BOLT CARRIAGE WZ (x8) 5/16x2 1/2 H100499 NUT BARREL WH WZ (x8) 5/16x7/8 A4M01018 SIDE BAR (x2) (x8) NUT BARREL - 7/8 (x8) BOLT - 2 1/2 TOP BAR ASSEMBLY (x1) WARNING LABEL STICKER (x4) NUT BARREL - 7/8 LEG ASSEMBLIES...
  • Page 19 STEP 4 A4M01136 CHAIN GREEN 48.25" (x4) A6P00373 26" HD BELT SWING H100242 (x2) QUICK LINK WZ (x4) (x4) CHAIN GREEN 48.25" (x4) QUICK LINK (LONG) WZ (x2) 26" HD BELT SWING...

  • Page 20: Washer Flat

    STEP 5 H100366 BOLT WH WZ (x4) 5/16x4 H100278 WASHER FLAT WZ (x4) 5/16 A6P00366 SWING SET FOOT A100178 (x4) H100499 NUT BARREL WH WZ AUGER GROUND STAKE (x4) (x4) 5/16x7/8 (x4) NUT BARREL - 7/8 (x4) BOLT - 4 (x4) WASHER FLAT - 5/16 (x4)
