Backyard Discovery MINI BRUTUS Owner's Manual & Assembly Instructions page 16

A4M01013
BOTTOM LEG
(x4)
A4M01015
TOP LEG
(x4)
NOTE: REPEAT THIS STEP 4 TIMES.
TIP: PLACE CARRIAGE BOLT BEFORE NUT BARREL.
NUT BARREL WH 5/16x7/8 WZ
NOTE: TWO VERTICAL
HOLES TOWARD TOP
015
(x1)
TOP LEG
020
(x2)
LEG CONNECTING TUBE
019
(x4)
METAL BRACKET GREY
013
(x1)
BOTTOM LEG
A4M01020
LEG CONNECTING TUBE
(x4)
A4M01019
METAL BRACKET GREY
(x8)
499
(x2)
STEP 1
591
BOLT CARRIAGE 5/16x2-1/2 WZ
DO NOT FULLY TIGHTEN BOLT
AS IT WILL BE REMOVED
IN A LATER STEP.
16
H100591 BOLT CARRIAGE WZ
(x4)
5/16x2 1/2
H100811 BOLT CARRIAGE WZ
(x4)
5/16x2 3/4
H100499 NUT BARREL WH WZ
(x8)
5/16x7/8
(x1)
811
(x1)
BOLT CARRIAGE 5/16x2-3/4 WZ
