Backyard Discovery MINI BRUTUS Owner's Manual & Assembly Instructions page 18

A6P00435
WARNING LABEL STICKER
(x1)
A4M01018
(x2)
WARNING LABEL STICKER
499
(x4)
NUT BARREL - 7/8
SIDE BAR
499
(x8)
NUT BARREL - 7/8
591
BOLT - 2 1/2
435
(x1)
018
(x2)
SIDE BAR
STEP 3
(x8)
18
H100591
BOLT CARRIAGE WZ
(x8)
5/16x2 1/2
H100499
NUT BARREL WH WZ
(x8)
5/16x7/8
TOP BAR ASSEMBLY
LEG ASSEMBLIES
REMOVE ASSEMBLED
HARDWARE SHOWN AND
ATTACH BRACE TO LEGS
THEN RE-ATTACH HARDWARE.
PLACE WARNING TAG STICKER
CENTERED ON LEG AS SHOWN.
(APPROXIMATE LOCATION)
