DEMO MANUAL DC2622A
Quick start proceDure
Connect the DC2622A to a DC2290A using the two output
SMA connectors J1, J3. Connect the +10V and –5V DC
supplies to the turrets on the DC2622A. Apply a 2.048V

HarDware setup

SIGNAL CONNECTIONS

J2 IN. This is the signal input.
J3 –OUT. This is the negative signal output.
J1 +OUT. This is the positive signal output.
2
Arrow.com. Arrow.com.
Downloaded from Downloaded from
DC voltage, preferably from E7 of the DC2290A, to 2.048V
in turret of the DC2622A.
