Associations Between Alarms and Dry
Table C-1 Associations between alarms and dry contacts
Port Type
Dry contact input
Dry contact output
The default setting (closed:
alarm; open: normal) can be
modified.
Issue 03 (2019-11-15)
Silk Screen Associated Alarm
DIN1 Dry contact input 1
DIN2 Dry contact input 2
DIN3 Dry contact input 3
DIN4 Dry contact input 4
DIN5 Dry contact input 5
DIN6 TEC Alarm
ALM1 Mains faults
ALM2 DC overvoltage and undervoltage
ALM3 Rectifier faults
ALM4 AC surge protective device (SPD) faults or DC SPD faults
ALM5 Battery or load fuse blown
ALM6 Excessively high or low ambient and battery temperatures
ALM7 Door status alarm
ALM8 Fan faults
