TP48200A-HT19C3 and TP48200A-HT19C4 Telecom
Power
User Manual
(10) Space for installing
batteries
(13) UIM
(16) AC SPD
3.2 PDU
TP48200A-HT19C3
Figure 3-3 shows the PDU for the TP48200A-HT19C3.
Figure 3-3 PDU for the TP48200A-HT19C3
(1) AC input circuit
breakers
(4) BLVD circuit breakers
TP48200A-HT19C4
Figure 3-4 shows the PDU for the TP48200A-HT19C4.
Issue 03 (2019-11-15)
The negative power cable of TCUA control box occupies the F10 BLVD circuit breaker.
Copyright © Huawei Technologies Co., Ltd.
(11) Space for installing
customer equipment
(14) SMU02B
(17) AC input circuit breaker
(2) AC surge protective device
(SPD)
(5) Battery circuit breakers
3 Components
(12) Space for installing
rectifiers
(15) DC PDU
(18) Battery switch (behind
the cover)
(3) LLVD circuit
breakers
22
