Highlights

General Highlights of the Intelligent
Series
♦ Complies with the IEEE 802.3 10BASE-T, 10BASE2, 10BASE5, and
10BASE-FL standards.
♦ Twelve or twenty-four independent RJ-45 ports for Category 3, 4, 5
twisted-pair wiring (either UTP or STP) to nodes in a 10BASE-T-
compliant network.
♦ Switchable uplink port allows stacks of hubs to be easily cascaded
together to further expand the network.
♦ Twisted-pair hub stack daisy chain cabling
◊ Allows a total distance of 100 meters between the first hub and the
last hub in the daisy-chain.
◊ Expandable network capacity up to 8 hubs in a single stack for a
maximum of 192 ports (and 8 AUI ports).
♦ Recessed AUI connector in the rear of the unit:
◊ Accommodates most standard Ethernet transceivers.
◊ Allows the transceiver to be safely and conveniently tucked away.
◊ A custom tray is provided for easy insertion and removal of a
recessed transceiver or cable.
♦ Clear, easy-to-read front panel display provides comprehensive
diagnostic indication of network status, allowing managers to
diagnose and troubleshoot instantly.
Introduction
10BASE-T Stackable Hubs
1-3
