Connectors, Controls, & Indicators
#
1
2
3
4
5
* Refer to "Operation" on page 14.
4 • infiNET
™
Lamp Dimmer: CLF-DIMRFB
CONNECTORS,
CONTROLS, &
INDICATORS
AC Receptacle
(ungrounded)
Foot Switch
LED Indicator
Mode Selection Switch
AC Plug
Crestron CLF-DIMRFB
3.51 in
(8.92 cm)
4' LONG, AC-PLUG, 3 CONDUCTOR
DESCRIPTION
Plug table/floor lamp in here
Operates dimmer*
Provides feedback*
Three-position switch sets
mode of operation*
Connects to 120V AC power
source
Operations Guide – DOC. 6479
