InfiNET Lamp Dimmer
The following table describes the LED pattern in all modes of operation:
LED Behavior
LED BEHAVIOR
LOW
HIGH
Four brief OFF blinks
every eight seconds.
Four brief HIGH blinks
every eight seconds.
Two brief OFF blinks
every eight seconds.
Blink OFF for ½ second,
LOW for ½ second.
Blink OFF for one second,
HIGH for one second.
Blink OFF for ¼ second,
HIGH for ¼ second.
1. Refer to "Enter ACQUIRE Mode" on page 16.
2. Refer to the Crestron Toolbox help file.
18 • infiNET ™
Lamp Dimmer: CLF-DIMRFB
Crestron CLF-DIMRFB
DEVICE STATE
In RUN mode, operating
normally.
Device is in the bootloader. Refer
to "Bootloader" on page 21 for
more information.
In RUN mode but there is no
communication with a gateway.
Device failed to acquire with a
1
gateway.
In RUN mode and communicating
with a gateway but the dimmer is
not addressed in a control system
program.
In SET mode.
The dimmer is in the Acquire
mode and searching for a
gateway.
This touch-settable device is
waiting for user to press a button
2
to identify it.
