InfiNET Lamp Dimmer

Operation

The CLF-DIMRFB may be warm to the touch during operation. This is
normal.

Mode Selection Switch

These dimmers use a three-position mode selection switch to set the
mode of operation.
OFF
When the mode selection switch is in the "OFF" position, the foot switch
will not have any function and the load is disconnected from the power
source. This must be used when changing light bulbs to ensure that the
load is fully disconnected from power.
RUN
When the mode selection switch is in the "RUN" position, it is operating
in the RUN mode. This is the normal operating mode of the dimmer. The
RUN mode is used to recall the preset light level. Refer to the following
table for a list of available functions when the dimmer is operating in the
RUN mode.
NOTE: To enter RUN mode, move mode selection switch to the "RUN"
position, without pausing at the "SET" position.
RUN Mode Functions
RUN mode entered
(from OFF mode).
RUN mode entered
(from SET mode).
(Continued on following page)
14 • infiNET ™
Lamp Dimmer: CLF-DIMRFB
EVENT
Crestron CLF-DIMRFB
ACTION
Recall last load state.
Store the current load level to the
preset level. (Refer to "SET Mode
Functions" on next page.) Cannot save
0%. Any level less than 10% will store
as 10%.
Operations Guide – DOC. 6479
