Crestron CLW-DIM User Manual

Introduction

Features and Functions

The CLW-DIM (-DIM) is a stand-alone wall box dimmer
that can also act as a Cresnet
®
Crestron control processor. The CLW-DIM has four
preset lighting levels that can be adjusted (refer to note
below). The CLW-DIM also includes two isolated, non-
polarized Cresnet wires (plus a ground wire) for
connecting to the Cresnet network over a twisted pair
wire with shield.
NOTE: The four preset levels are noted as Button 1-
High, Button 1-Low, Button Preset 2, and Button Preset
3. Preset "Button 1-High" is usually used for turning
lights on to full brightness while preset "Button 1-Low" is
usually used for turning the lights off. Although "1-High"
and "1-Low" are usually used for "On" and "Off"
respectively, the light level for each preset can be
customized by the user. Refer to "Operating Buttons and
Switches" on page 5 for more information on customizing
light levels.
The CLW-DIM features a three-position mode selection
switch. Refer to "Operating Buttons and Switches" on
page 5 for more information. In the absence of Cresnet
communications, the dimmer can still be used to control
lighting.
The CLW-DIMS (-DIMS) is similar to the -DIM with the
added capability of working with a slave unit
(CLW-SLVD) in a multi-switch / single circuit
application.
The CLW-SLVD (-SLVD) is a slave unit that when used
in conjunction with the -DIMS acts as an additional
dimmer control point in a multi-dimmer / single circuit
application. It does not connect to a Cresnet system and
cannot be used without a -DIMS. The -SLVD does not
have a mode selection switch and is not programmable. It
emulates the operation of the -DIMS to which it is
connected.
The -DIM, -DIMS, and -SLVD are available in white,
almond, and black. White units are designated by part
numbers ending in "W". Almond units are designated by
part numbers ending in "A". Black units are designated by
part numbers ending in "B". Each dimmer can be covered
with a decorative faceplate (not supplied).
Crestron Electronics, Inc.
15 Volvo Drive Rockleigh, NJ 07647
Tel: 888.CRESTRON
Fax: 201.767.7576
www.crestron.com
®
device that reports to a
CLW-DIM, DIMS, & SLVD(W/A/B)

Specifications

Following are specifications for the -DIM, -DIMS, and
-SLVD.
CLW-DIM, CLW-DIMS, & CLS-SLVD Specifications
SPECIFICATION
Power Requirements
Default Net ID
Switch Type
Load Type
2-Series Control System
1,2
Update File
3
Load Ratings
Incandescent/Tungsten
Halogen
Magnetic Low Voltage
Operating Temperature
and Humidity
Dimensions and Weight
1. The latest software versions can be obtained from the Crestron
website. Refer to the NOTE following these footnotes.
2. Crestron 2-Series control systems include the AV2 and PRO2.
Consult the latest Crestron Product Catalog for a complete list of
2-Series control systems.
3. Refer to Derating Charts for Multigang Installations on page 3.
4. VA ratings are for input power to the transformer. If you do not
know the input power requirement of the transformer, use the
bulb's wattage rating to determine proper rating.
NOTE: Crestron software and any files on the website
are for Authorized Crestron dealers and Crestron
Authorized Independent Programmers (CAIP) only. New
users may be required to register to obtain access to
certain areas of the site (including the FTP site).
DETAILS
Line Power, 120 VAC, 60 Hz
-DIM: 6D
-DIMS: 6E
Dimmer
Incandescent, Tungsten-Halogen,
Magnetic Low Voltage
Version 3.093 or later
-DIM: 1000W
-DIMS: 1000W
-SLVD: N/A
4
-DIM: 1000VA/750W
-DIMS: 1000VA/750W
-SLVD: N/A
32°F to 104°F (0°C to 40°C)
10 to 90% Relative Humidity
(Non-Condensing)
-DIM and -DIMS:
Height: 4.13 in (10.48 cm)
Width: 2.38 in (6.03 cm)
Depth: 1.91 in (4.85 cm)
Weight: 4.9 oz (0.67 kg)
-SLVD:
Height: 4.13 in (10.48 cm)
Width: 1.75 in (4.45 cm)
Depth: 1.91 in (4.85 cm)
Weight: 3.6 oz (0.50 kg)
Installation Guide – DOC. 5995B
(2002077)
Specifications subject to
change without notice.
