Setup

Identity Code

The MNET ID of the CLF-DIMRFB has been factory set to 01. After an
infiNET device is added to an infiNET network, its MNET ID must be
changed to a value that can be addressed by the control system program
(03 to 20). The MNET IDs of multiple CLF-DIMRFB devices in the
same system must be unique. MNET IDs are changed from a personal
computer (PC) via the Crestron Toolbox. When setting the MNET ID,
consider the following:
• The MNET ID of each unit must match an ID code specified in the
• Each network device must have a unique MNET ID.
For more details, refer to the Crestron Toolbox help file.

Hardware Hookup

Make the necessary connections as called out in the illustration that
follows this paragraph. Apply power after all connections have been
made.
When making connections to the CLF-DIMRFB, consider the following:
• The included cable cannot be extended.
• Do not use an extension cord.
6 • infiNET ™
Lamp Dimmer: CLF-DIMRFB
SIMPL Windows or D3 Pro
Crestron CLF-DIMRFB
™ ™
/SystemBuilder
Operations Guide – DOC. 6479
program.
