RUN Mode Functions (Continued)
Foot switch is
pressed.
SET
When the mode selection switch is in the "SET" position, it is operating
in the SET mode. The LED will blink to indicate that the dimmer is in the
SET mode. Refer to the following table for a list of available functions
when the dimmer is operating in the SET mode.
NOTE: Mode selection switch must be in the "SET" position for at least
0.5s for unit to enter SET mode.
SET Mode Functions
SET mode entered
(from OFF or RUN
mode).
Foot switch is
pressed.
* Fade time and ramp time are parameters that can be changed in SIMPL
Windows. Refer to the SIMPL Windows help file (F1) for details.
Operations Guide – DOC. 6479
EVENT
EVENT
infiNET
ACTION
Toggle between the preset level and
OFF, using the following rule:
If load is currently OFF, recall preset,
otherwise turn load OFF.
ACTION
Set the load to the preset level using a
0s fade* (or the minimum allowed
fade).
LED will blink at a steady rate while in
this mode (refer to "LED Behavior" on
page 17.
Manually raise or lower the load using
the current "ramp time"* parameter.
The behavior will be alternating;
releasing the button and pressing it
again will cause the lights to ramp in
the opposite direction. Switch to "RUN"
mode to store preset.
(User can abort any changes made in
SET mode by switching unit OFF
before returning to RUN.)
™ Lamp Dimmer: CLF-DIMRFB • 15
