Crestron C2N-SDC-DC
NOTE: The UP ▲button applies +24 VDC to pin A (referenced to pin
B). The DOWN ▼ button applies +24 VDC to pin B (referenced to pin
A). If the shade does not go in the desired direction when the button is
pressed, reverse the polarity of the shade motor wires.
Installation
The C2N-SDC-DC may be mounted in a two-gang electrical box or a
4 x 4 inch (1900) electrical box. Ensure that you are using a box with
sufficient depth (minimum 1.5 inch) to accommodate the device.
Screws are included for both mounting locations.
Included Mounting Hardware
QUANTITY
Tools Required:
Two-Gang Box Mounting
When mounting in a two-gang electrical box, use the four 06-32 3/8" pan
head screws as shown in the following illustration.
Operations & Installation Guide - DOC. 6373
4
06-32 x 3/8" Pan Head
Screw
2
08-32 x 3/8" Pan Head
Screw
Phillips screwdriver
•
Shade & Drape DC Motor Controller
PART
Two-Gang Electrical Box
Mounting (not provided)
4 X 4 inch (1900)
Electrical Box Mounting
(not provided)
Shade & Drape DC Motor Controller: C2N-SDC-DC 11
