Shade & Drape DC Motor Controller
lockout timer that shuts the motor off for a brief time before allowing the
motor to reverse direction. Additional control is available via Cresnet.
Four pushbuttons on the face of the unit allow the motors to be activated
without Cresnet control, which is particularly useful when operating the
unit locally during installation.

Specifications

The following table summarizes the specifications for the C2N-SDC-DC.
Specifications of the C2N-SDC-DC
SPECIFICATION
Cresnet Power Usage
Default ID
Control System Update
Files
2-Series Control System
CNMSX-AV/PRO
CNRACKX/-DP
CEN/CN-TVAV
Firmware Version
Motor Input Power
Load Types
Maximum Load per Motor
Operating Temperature
Humidity Range
Dimensions
Weight
2 Shade & Drape DC Motor Controller: C2N-SDC-DC
2, 3, 4
1. Does not include power for the motors. For example, add 10 Watts for
each Somfy LT28B shade motor. Three Watts are consumed by the
C2N-SDC-DC when the motors are not operating. Motor loads may be
connected to the C2N-SDC-DC up to the available power remaining on
the Crestron power supply. Crestron recommends that the available power
be de-rated by a factor of two to allow for the inrush motor current that
Crestron C2N-SDC-DC
DETAILS
3 Watts (0.125 Amps @ 24 VDC)
23
Version 3.117.CUZ or later
Version 5.14.02X.UPZ or later
Version 5.12.63W.UPZ or later
Version 5.12.63V.UPZ or later
C2N-SDC-DC.v1.0.upg
24 VDC from Cresnet
2-wire Bi-directional DC Motor
30 W each channel, 30 W total
41º to 122ºF (5º to 50ºC)
10% to 90% RH
Height: 4.10 in (10.42 cm)
Width: 4.10 in (10.42 cm)
Depth: 1.16 in (2.95 cm)
0.55 lb (0.25 kg)
Operations & Installation Guide - DOC. 6373
