THORLABS vytran LDC450B User Manual page 50

LDC450B Large Diameter Cleaver
Top Insert Item #
VHA00
Accepted Diameter
≤320 µm
(Nominal)
Bottom Accepted
Insert Diameter
Item # (Nominal)
b
VHD160 or 112/208
160 µm
b,c
-49/48
VHF160
b
VHD250 or
177/320
250 µm
b,c
-73/69
VHF250
b
VHD400 or 279/519
400 µm
b,c
-122/119
VHF400
b
VHD500 or 346/592
500 µm
b,c
-153/93
VHF500
b
VHD750 or
516/759
750 µm
b,c
-234/9
VHF750
1000 µm -
a
VHE10
1250 µm -
1500 µm -
a
VHE15
1750 µm -
2000 µm -
a
VHE20
2250 µm -
VHE25 2500 µm -
VHE30 3000 µm -
Best Fit
a. These inserts have two grooves, one on each side, that each accommodate a different range of fiber sizes, except for the VHA00, which
has a flat surface on one side that can be used to clamp the smallest fiber sizes.
b. These bottom inserts have vacuum holes to aid in aligning small fibers when used with the LDC401 and LDC401A large-
diameter fiber cleavers.
c. These are transfer inserts. When used with the VHT1 transfer clamp, they allow the fiber to be transferred between stripping, cleaning,
cleaving, splicing, and tapering stations without losing registration of the fiber tip location relative to the edges of the fiber holding block.
Here are instructions for using the charts on this page.
1. First, select the Bottom Insert that matches your fiber size most closely.
Example: For an Ø800 µm fiber, the VHD750 insert is the closest match, since it is only 50 µm smaller.
2. On the chart below, look to the right of your chosen Bottom Insert. Select a compatible Top Insert
based on the fiber diameter size range shown in each cell.
Example: For the Ø800 µm example fiber from step 1, the green cell is in the 750 µm groove column for
the VHA05 Top Insert which has two grooves. The numbers listed in the green cell indicate that this
combination of Inserts is good for fibers from 728 to 963 µm in diameter. Our Ø800 µm fiber is within this
range, so this is a good choice. There are several other options as well that will accommodate an Ø800 µm
Page 46
Fiber Holder Insert Selection Chart
a
a
VHA05
400 µm 500 µm 750 µm
- -
275/323
- -
25/74
377/517 410/519
-
-23/117 -9/119
447/647
476/711 560/795
-53/147
-24/211 61/296
617/970
643/878 728/963
-132/221
-107/128 -23/213
773/1008 858/1093
-172/63 -88/147
1034/1269
-
-176/59
- -
- -
- -
- -
- -
- -
Try these options if the best fit does not
Figure 44 Each Insert Can Hold a Range of Fiber Sizes
a
VHA10 VHA15
1000 µm 1250 µm 1500 µm
Min/Max Accepted Diameter (µm)
Min/Max Offset (µm)
- - -
- - -
- - -
- - -
812/1047
- -
62/297
943/1178 1036/1271
-
-3/232 90/325
1119/1354 1212/1447 1288/1523
-91/144 2/237 78/313
1280/1515 1373/1608 1449/1684
-172/63 -79/156 -2/233
1534/1770 1611/1846
-
-159/76 -83/152
1787/2022
- -
-171/64
- - -
- - -
- - -
Legend
Second Best Fit
incorporate your fiber sizes.
Chapter 9: Accessories
a a
VHA20
1750 µm 2000 µm 2250 µm
- - -
- - -
- - -
- - -
- - -
- - -
- - -
1534/1769
- -
82/314
1695/1930 1772/2007
-
2/237 78/313
1871/2106 1947/2183 2032/2267
-86/149 -10/225 74/309
2033/2268 2109/2344 2193/2429
-167/68 -91/144 -6/229
2270/2505 2355/2590
-
-172/64 -87/148
2692/2944
- -
-256/-4
Third Best Fit
Try these options if the other two categories
do not incorporate your fiber sizes.
TTN197399-D02
VHA25 VHA30
2500 µm 3000 µm
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
2278/2513
78/313 -
2439/2675 2609/2844
-2/233 167/402
2777/3029 2946/3198
-171/81 -2/250
