4.2.

Optionally coding of ParkAssist to retrofit factory PDC (only PCM3.1)

Steering-wheel buttons left

It is necessary to code the ParkAssist of the PCM 3.1 to retrofit factory PDC.

1. Turn on ignition

2. Wait until the head-unit has booted

3. Press and hold steering-wheel button BACK

4. Press and hold steering-wheel button ACCEPT (observe the sequence!)

5. Hold both buttons. During configuration the red and

blue LED are blinking inside the CAN-box (visible at the

male 8pin Molex connector). The PCM makes a reset

after 5-10 sec.

6. Disengage both steering-wheel buttons

7. The red and the blue LED inside the CAN-Box are

glowing and the menu „ParkAssist" appears in the

menu OPTION after a successful coding

It is possible to decode the ParkAssist as follows:

1. Turn on ignition

2. Wait until the head-unit has booted

3. Press and hold steering-wheel button BACK

4. Press and hold steering-wheel button HANG UP (observe the sequence!)

5. Hold both buttons. During configuration the red and blue LED are blinking inside the

CAN-box (visible at the male 8pin Molex connector). The PCM makes a reset after 5-

10 sec.

6. Disengage both steering-wheel buttons

7. The red and the blue LED inside the CAN-Box are glowing and the menu „ParkAssist"

disappears in the menu OPTION after a successful decoding

Version 17.03.2021

HASH KEY/MODE

BACK

HANG UP

Steering-wheel buttons right

RL-PCM3-2-TF
