r.LiNK-Interface
RL-FD79-TF
Rear view camera input
compatible with Ford and
Sony 8" MYFORD Touch Radios
Legal Information
By law, watching moving pictures while driving is prohibited, the driver must not be
distracted. We do not accept any liability for material damage or personal injury resulting,
directly or indirectly, from installation or operation of this product. This product should only
be used while standing or to display fixed menus or rear-view-camera video when the
vehicle is moving, for example the MP3 menu for DVD upgrades.
Changes/updates of the vehicle's software can cause malfunctions of the interface. We
offer free software-updates for our interfaces for one year after purchase. To receive a free
update, the interface must be sent in at own cost. Labor cost for and other expenses
involved with the software-updates will not be refunded.
Version 01.03.2019
RL-FD79-TF

Advertisement

Table of Contents
loading

Related Manuals for Caraudio-Systems r.LiNK RL-FD79-TF

Summary of Contents for Caraudio-Systems r.LiNK RL-FD79-TF

  • Page 1 r.LiNK-Interface RL-FD79-TF Rear view camera input compatible with Ford and Sony 8” MYFORD Touch Radios Legal Information By law, watching moving pictures while driving is prohibited, the driver must not be distracted. We do not accept any liability for material damage or personal injury resulting, directly or indirectly, from installation or operation of this product.

  • Page 2: Table Of Contents

    Contents 1. Prior to installation 1.1. Delivery contents 1.2. Check compatibility of vehicle and accessories 1.3. Dip-switch settings of the CAN-Box RLC-FO01-A modules 1.4. Pin-assignments 1.5. Connection schema 2. Installation 3. Rear-view camera connection 4. Activation of the video-in-motion function 5.

  • Page 3: Check Compatibility Of Vehicle And Accessories

    1.2. Check compatibility of vehicle and accessories Requirements Vehicle Ford 2011 - 2014 Edge 2011 - 2014 Explorer 2012 - 2014 Focus 2013 - 2014 Focus ST 2013 - 2014 Taurus 2013 - 2014 Escape F-150 2013 - 2014 F-150 Raptor F-250 2013 - 2014 F-350 2013 - 2014 F-450 2013 - 2014 F-550...

  • Page 4: Dip-Switch Settings Of The Can-Box Rlc-Fo01-A Modules

    1.3. Dip-switch settings of the Can-Box RLC-FO01-A modules Setting the Dip-switches of the Can-Box RLC-FO01-A connected on the 500KB 8Pin Molex plug Vehicle/ navigation Dip 1 Dip 2 Dip 3 Dip 4 Dip 5 Dip 6 Video-in-motion permanent Video-in-motion selective* * With dip1 to OFF the included green cables are used to activate the video-in-motion function.

  • Page 5: Pin-Assignments

    1.4. Pin-assignments Pin-assignment vehicle connector Assignment +12Volt Permanent - Pin 1 Ground - Pin 37 CAN HIGH (500KB) - Pin 19 CAN LOW (500KB) - Pin 18 CAN HIGH (125KB) - Pin 16 CAN LOW (125KB) - Pin 17 Pin-assignment of the CAN-Box RLC-FO01-A (Molex 8pin) Cable colour Pin-No.

  • Page 6: Connection Schema

    1.5. Connection schema 2. Installation Switch off ignition and disconnect the vehicle’s battery! If according to factory rules disconnecting the battery has to be avoided, it is usually sufficient to put the vehicle is sleep-mode. In case the sleep-mode does not show success, disconnect the battery with a resistor lead.

  • Page 7: Rear-View Camera Connection

    6. When the radio powers up, turn the radio ON and select the FM Radio source. This step simply helps in verifying the interface is corresponding with the radio. 7. While listening to the FM Source, place dip switch number “2” to the “ON” position on the RLC-FO01-A module connected on the 125kb 8-Pin connector.

  • Page 8: Activation Of The Video-In-Motion Function

    4. Activation of the video-in-motion function The video-in-motion can be activated and deactivated by Dip 1 on both RLC-FO01-A modules or alternatively by steering wheel buttons or over the loose green cables in connection with a switch (not included in delivery). Option 1: Video-in-motion permanent With dip1 to ON on both RLC-FO01-A modules the video-in-motion function is activated permanently.

  • Page 9: Specifications

    Temperature range -30°C to +80°C Weight Measurements (box only) W x H x D 76 x 27 x 54 mm 6. Technical support Caraudio-Systems Vertriebs GmbH manufacturer/distribution In den Fuchslöchern 3 D-67240 Bobenheim-Roxheim email support@caraudio-systems.de Legal disclaimer: Mentioned company and trademarks, as well as product names/codes are registered trademarks ®...
