- Page 1 RL-LR12-TF Rear-view camera-input video-in-motion for Landrover touch-screen navigation systems from model 2012 Only for vehicles WITHOUT factory rear-view camera Version 28.05.2014 RL-LR12-TF...
-
Page 2: Table Of Contents
To receive a free update, the interface must be sent in at own cost. Labor cost for and other expenses involved with the software-updates will not be refunded. Version 28.05.2015 RL-LR12-TF... -
Page 3: Prior To Installation
Check compatibility of vehicle and accessories Requirements Vehicle Land Rover Range Rover Evoque L538, Range Rover Sport L320, Discovery 4 L319 from year 2012 Navigation Touch-screen navigation version 3 Limitations After-market rear-view Only compatible with NTSC-cameras. camera Version 28.05.2015 RL-LR12-TF... - Page 4 Setting dip 2 to ON codes the factory rear-view camera input which is located on the brown Fakra male connector of the factory monitor. When reverse gear is engaged, the navigation will automatically switch to this input. On vehicles with factory rear-view camera set Dip 2 to ON, too. Version 28.05.2015 RL-LR12-TF...
-
Page 5: Pin-Assignments
CAN-LOW – connection to the vehicle ● Pin 1 +12V permanent ● Black Pin 5 Ground ● Green Pin 6 Activation of the video-in-motion function (+12V = TV-free activated) ● White Pin 2 Trigger output (+12V DC 500mA) Version 28.05.2015 RL-LR12-TF... -
Page 6: Connection Schema
In case the sleep-mode does not show success, disconnect the battery with a resistor lead. Place of installation is on rear of the factory navigation monitor. Version 28.05.2015 RL-LR12-TF... -
Page 7: Interconnecting Can-Box, Harness And Factory Navigation Monitor
Connect female Fakra-connector of adapter CAB-TV-AS20 to the male purple Fakra- connector on the rear of the factory navigation monitor. Connect the video RCA of the rear-view camera to the female RCA connector of adapter CAB-TV-AS20. Note: Only compatible with NTSC-cameras. Version 28.05.2015 RL-LR12-TF... -
Page 8: Activation Of The Video-In-Motion Function
Connect a switch to the green cable and connect the green cable to +12V ACC. ● +12V = TV-Free is activated ● = TV-Free is not activated Note: The loose white cable is not required and must be isolated. Version 28.05.2015 RL-LR12-TF... -
Page 9: Specifications
Stand-by power drain <2mA Operation power drain ~60mA Power consumption ~0,08W Temperature range -30°C to +80°C Weight Measurements (box only) W x H x D 70 x 20 x 47 mm/ 76 x 27 x 54 mm Version 28.05.2015 RL-LR12-TF...
