TV-Free
Video-in-motion Interface
TF-MFD2
for Audi RNS-E,
Volkswagen MFD2/RNS2
and Skoda Nexus
navigation systems
Legal Information
By law, watching moving pictures while driving is prohibited, the driver must not be
distracted. We do not accept any liability for material damage or personal injury resulting,
directly or indirectly, from installation or operation of this product. This product should only
be used while standing or to display fixed menus or rear-view-camera video when the
vehicle is moving, for example the MP3 menu for DVD upgrades.
Changes/updates of the vehicle's software can cause malfunctions of the interface. We
offer free software-updates for our interfaces for one year after purchase. To receive a free
update, the interface must be sent in at own cost. Labor cost for and other expenses
involved with the software-updates will not be refunded.
Version 13.09.2012
TF-MFD2
Advertisement
Table of Contents
Related Manuals for Caraudio-Systems TV-Free TF-MFD2
Summary of Contents for Caraudio-Systems TV-Free TF-MFD2
- Page 1 TV-Free Video-in-motion Interface TF-MFD2 for Audi RNS-E, Volkswagen MFD2/RNS2 and Skoda Nexus navigation systems Legal Information By law, watching moving pictures while driving is prohibited, the driver must not be distracted. We do not accept any liability for material damage or personal injury resulting, directly or indirectly, from installation or operation of this product.
- Page 2 Contents 1. Prior to installation 1.1. Delivery contents 1.2. Check compatibility of vehicle and accessories 1.3. Setting the Dip-switches of the CAN-Box TV-400 1.4. Pin-assignments 2. Installation 3. Activation of the video-in-motion function 4. Specifications 5. Technical support 1. Prior to installation Read the manual prior to installation.
- Page 3 1.2. Check compatibility of vehicle and accessories Requirements Vehicle Audi A3, A4, TT (8J), VW Touareg; Golf 5, Touran, T5, Passat from years 2006, Caddy Live, Skoda Octavia 2 and other vehicles with MFD2/RNS2 navigation systems Navigation Audi Navi Plus RNS-E, VW MFD2/RNS2 and Skoda Nexus navigation systems Attention! Audi A6 with Navi Plus RNS-E have analog speed signal.
- Page 4 2. Installation Switch off ignition and disconnect the vehicle’s battery! If according to factory rules disconnecting the battery has to be avoided, it is usually sufficient to put the vehicle in sleep-mode. In case the sleep-mode does not show success, disconnect the battery with a resistor lead.
- Page 5 Instruction for VW Golf 5, Touran and Skoda with MFD2/RNS2/Nexus: 1. Remove decorative plastic panels of the navigation computer carefully, remove the 4 TORX screws and pull the navigation computer out of the centre console. 2. Disconnect Quadlock connector from the backside of the navigation computer and connect it to harness TV-VW01.
- Page 6 ~0,72W Temperature range -30°C bis +80°C Weight Measurements (box only) B x H x T 70 x 20 x 47 mm 5. Technical Support Caraudio-Systems Vertriebs GmbH NavLinkz GmbH manufacturer/distribution corporate sales/tech dealer-support Rheinhorststr. 22 Eurotec-Ring 45 D-67071 Ludwigshafen am Rhein...
