- Page 1 Dome Fixed-Focal/Vari-Focal Bullet Auto Focus Day & Night IR IP Camera User Manual Version 1.0...
- Page 2 You can count on us for quick response. Email: service@icpdas.com For more product information please refer to website: https://ww.icpdas.com Technique: Kevin Ho, Edition: Eva Li, R&D Dept., ICP DAS CO., LTD. Latest edited by: Eva Li, V.1.0, 01/2021 iCAM-MR/ZMR Series User Manual ICP DAS...
-
Page 3: Table Of Contents
Chapter 6 Advance Mode Setting ......................37 6-1 System ............................ 37 6-1-1 System Log .......................... 37 6-2 Video/Audio ........................... 37 6-2-1 Quality Advance ........................37 6-2-2 Day Mode / Night Mode ..................... 38 6-2-3 AGC/Sense Up+ ........................39 iCAM-MR/ZMR Series User Manual ICP DAS... - Page 4 6-5-7 MQTT Service ........................51 Appendix .............................. 52 DDNS and PPPoE Network Settings ..................... 52 Advanced Port Forwarding Technology ..................52 Restore to Factory Default ......................53 For iPhone Users .......................... 54 For Android Users ........................55 iCAM-MR/ZMR Series User Manual ICP DAS...
-
Page 5: Summary
Other References Mobile devices For mobile surveillance, refer to the detail page of IPCamPlus on Apple App Store or Google Play. Universal ActiveX Control: For viewing MJPEG, H.264 real-time images in Microsoft's IE browser. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 6: Caution
Do not damage the power cord or leave it under pressure To avoid unnecessary magnetic interference, do not operate this unit near magnets, speaker systems, etc. All connection cables should be grounded properly iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 7: Document Version Modify List
Document Version Modify List: Date Version Description The First Version: Edit and modify to the format of ICP DAS Add Chapter 2: Connect WISE and iCAM 2021/01/21 Modify and delete content iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 8: Chapter 1 System Overview
WISE-523x/WISE-2x4xM supports LINE Notify, which can send photos of the event and various on-site data (such as temperature, door opening and closing status) to the mobile phone immediately. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 9: Integrating Wise Edge Controller With Icam Ip Camera
WISE-523x/WISE-2x4xM provides the IP Camera Status webpage to display the event list ordered by time, and you can just click and play the images or videos on the browser. In additional, WISE-523x/WISE-2x4xM provides remote backup mechanism to upload images and videos to the remote FTP server automatically iCAM-MR/ZMR Series User Manual ICP DAS... - Page 10 2 LINE notifies to delivery completed information. Since the text message is directly embedded on the screen, a single image can fully express the picture and data at the time of the event. iCAM-MR/ZMR Series User Manual ICP DAS...
-
Page 11: Software Requirements
Windows OS. Click Install and follow the instructions to install the necessary components. In addition, please go to http://www.adobe.com/products/flashplayer to download the Flash player to control the PTZ control panel. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 12: Chapter 2 Set Up Icam Via Wise Controller
1.4.0 or above firmware version Default login admin / pass account / password Record video 10~60 seconds (configurable) length OSD message English, Chinese setting function Motion Detection Supported Event Type Tampering Detection Network Lost Detection iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 13: Flowchart Of Setting Wise And Icam
OSD message on Set Motion Detection: record (Video length fixable iCAM in setting time. Detect Range, Time & can fit to OSD message) Enable OSD content, OSD time, Change OSD text size iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 14: Add Icam Ip Camera
Figure3：Set up the Model Name of the IP Cameras iv. Click to add the IP Camera to the list. After adding the IP Camera, click “Save” button to save the changes. Figure4: Add the IP Cameras iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 15: Ip Camera List Operation Interface
Remove: Click the radio button in front of the iCAM IP Camera and click on “Remove” to remove the selected iCAM IP Camera. After all settings are completed, click “Save” button to save the changes. The following will describe the setting of ICP DAS iCAM IP Camera. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 16: The Setting Of Icam Ip Camera (Use Wise)
Connection Testing: The user could test if the IP Camera setting is correct or not. After clicking “Testing” button, the WISE will verify the connection status with the IP Camera and reply the result. iCAM-MR/ZMR Series User Manual ICP DAS... - Page 17 "Duration"; or set “Change the content” to change the content and the color of the OSD message with the iCAM-MR/ZMR Series User Manual ICP DAS...
- Page 18 Camera. If the OSD message cannot be displayed completely, please reduce the character number of the message. After all settings of the IP Camera are completed, click “OK” button to save the changes and return to IP Camera List. iCAM-MR/ZMR Series User Manual ICP DAS...
-
Page 19: The Setting Of Icam Ip Camera (Use Icam)
IF Condition or THEN/ELSE action, or requires the iCAM IP Camera to report the status of Motion detection to WISE, please complete the Event setting of iCAM IP Camera in advance. The setting screen references are as below: 8: iCAM IP Camera Motion Detection Range Setting Page Figure iCAM-MR/ZMR Series User Manual ICP DAS... - Page 20 FTP settings on the iCAM about FTP of the event. The WISE will automatically assign the FTP settings into the iCAM IP camera. ※ If you need more detailed information, please refer to the WISE user manual for advanced function settings. iCAM-MR/ZMR Series User Manual ICP DAS...
-
Page 21: Chapter 3 Before Accessing Ip Cameras
To configure the IP address of your cameras, download IPScan from our official website. To change the IP address, subnet mask, gateway, or HTTP port of your cameras, follow the steps below: Run the IPScan utility Click Refresh. All available devices will be listed on the screen iCAM-MR/ZMR Series User Manual ICP DAS... - Page 22 Click Apply for the changes to take effect Click Refresh again to verify the changed settings If the device cannot be scanned, check "ONVIF" & "ONVIF Deep Search" in the device type and refresh again. iCAM-MR/ZMR Series User Manual ICP DAS...
-
Page 23: Web Browser Settings & Software Components Required
Once completed, you can access the IP camera’s live video by entering the default IP address via a web browser. A security warning dialog box will appear. Click OK to download the ActiveX directly from the IP camera. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 24: Chapter 4 Ip Camera Operations
When logged in as an administrator, two main features are available: 1) camera operations and 2) configurations. Quick buttons—IP camera shortcuts ActiveX display screen—Display RTSP H.264 or MJPEG streaming video Profile switching menu—Switching from one profile to another Setup buttons—IP camera setup menu Zoom & Focus control panel iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 25: Control Functions
Move your cursor to the PIP window and drag inside it to perform ePan and eTilt actions. The scroll wheel can be used to zoom in and zoom out. (Bullet type ZMR-8422X supports this.) Right-click on the video to exit the ePTZ mode. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 26: Quick Buttons
4-3-1 Record to a Local PC To record to a local PC, right-click anywhere on the screen. Choose Setting to specify the recording paths and recording sizes, and choose Recording On to start recording. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 27: Chapter 5 Basic Mode Setting
OS Version: The version number of the camera System Reboot Time: The last time your system was rebooted. Device Name: The device name can be found using the IPscan utility, which allows you to iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 28: User
Enter the account name and password for the new account, and then check to assign the access rights for this account. To edit account information, click Edit User. To delete a user, click Remove User. Click Submit to update the settings. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 29: Timer
Note: This function requires Internet connection. To synchronize with an WISE controller, need to set up the IP camera on the WISE. Enable the “Time Synchronization”, and the WISE will synchronize the IP camera time. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 30: Video / Audio
Alarm Weighted Mode: Enable to prioritize as the output stream you want to see when an alarm is detected RTSP URL: Allows you to see the video stream through the Real Time Streaming Protocol Image Quality: The compression rate of the MJPEG stream iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 31: Smart H.264
Window Enable: Enable Smart H.264 window. End Edit: Finish defining the setting of Smart H.264 window. Clean: Clean the current defined Smart H.264 window. Clean All: Clean all the defined Smart H.264 windows. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 32: Quality Basic
5-2-3 Quality Basic This menu allows you to adjust brightness, auto contrast, contrast, hue, saturation, and sharpness both for the Day Mode and Night Mode. Individual day/night settings ensure the camera to provide optimal video quality. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 33: Network
Default DNS—The IP address of the default and first DNS server Second DNS IP Address—The IP address of the backup and second DNS server to the default DNS PPPoE Account—Username of the PPPoE service PPPoE Password—Password of the PPPoE service iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 34: General Ipv6
RTSP Package Size: Choose the size of each RTSP package depending on your bandwidth METADATA: Enable/disable METADATA RTCP Check: Enable to send RTCP packages for transmission optimization Repeated Delivery of SPS/PPS: Enable to send SPS/PPS information before I frames iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 35: Https Service
RTSP Authentication: Enabling this option will require username and password when connecting to the RTSP stream Video Port: Choose between HTTP or RTSP/UDP for your stream Profile Name: Change the profile name 5-3-4 HTTPs Service iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 36: Maintenance
In the Maintenance page, you can click Load Default to restore the camera to factory settings, or click Reboot System to restart the camera. Warning: Never disconnect the power during the update. This could cause irreversible damage to your device. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 37: Chapter 6 Advance Mode Setting
6-2-1 Quality Advance In this page, you have access to Exposure, Automatic Gain Control, White Balance Control, Sense Up, Shutter Speed, IR-Cut, and Iris settings allowing you to adjust camera video quality for day and night. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 38: Day Mode / Night Mode
Color Mode: switch between color/black-and-white mode IR LED: Turn on to activate the infrared LED IR Cut Filter: enable/disable the IR cut filter Without Sense Up Sense Up by 3 Frames iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 39: Agc/Sense Up
The IP camera contains HDR or WDR for strong back light environment. Turn on HDR mode if the camera points to strong light environment. Note: Once HDR mode is activated, video frame rate and resolution get dropped. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 40: Auto Focus
Day Mode: fix the camera to day mode Night Mode: fix the camera to night mode and turn on the infrared function Schedule: Set the switching time of day/night mode Note: IR-cut camera model only. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 41: Roi
The IP camera provides up to 4 sets of privacy masking. Select any of the masking numbers and drag to mask specific areas. Select Clean to clean one set, select Clean all to clean all 4 sets. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 42: Lens Distortion Correction
Click Zoom and Strength features for the correction. Warning: LDC feature does not support 4:3 resolution ratio for the main stream. For LED feature, please set the main stream at 16:9 resolution ratio. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 43: Network
Note: The user does not need to set the stream setting value that IP camera to connect with the WISE controller here. The WISE controller will issue a CGI command to the Camera to set a specific value. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 44: Ip Address Filtering
Bonjour is Apple’s implementation of zero-configuration networking protocol. Click Enable to activate this service. 6-3-5 SDDP/Heartbeat With SDDP/Heartbeat support, you can connect to any compatible devices. Enable the service before you make the connection. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 45: Event
SAMBA Service: If event is detected, send alarms to the device linked with the iCAM in the preset time. HTTP POST Service: If event is detected, send JPEG images to the filled URL website in the preset time. To change the action and event types, go to the detail settings. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 46: Ivs Setting
Once the above configurations are set, click Motion Detection to determine the areas to monitor. Simply double-click or drag across the areas you want to monitor, and cancel your selection by double-click again or drag across the areas you don’t want to monitor with the right mouse button. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 47: Tampering Detection
ID of the push phone. You can use this form to determine whether IPCamPlus has completed the connection with the camera. Click Delete to cancel the push service of the mobile phone. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 48: Notification
Date format—date string for the JPEG filename Postfix—postfix of the JPEG filename 6-5-2 SMTP (Email) Service For alarm notification with JPEG snapshots, enter the required information to enable this Email notification service. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 49: Http Post Service
Ensure to click Unmount before removing the SD card, or the system may crash. 6-5-5 SD Card Backup To download a specific clip, right-click the file you want to download and save the AVI file to a local PC. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 50: Samba Service
Samba Server Directory: The target path of the recordings on the Samba server Samba Status: The connection status of the Samba server Samba Total Bytes: The storage size of the Samba server Samba Free Bytes: The free storage size of the Samba server iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 51: Mqtt Service
MQTT UUID: The MQTT UID of the camera Authentication: Enable authentication for accessing the IP camera Account: The account for accessing the IP camera Password: The password for accessing the IP camera iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 52: Appendix
IP of 192.168.0.11. When a remote PC on the Internet tries to access the port 81, the user is actually accessing 192.168.0.11, private IP given by the router. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 53: Restore To Factory Default
4. Access the IP camera via an Internet browser. 5. Enter the default username (admin) and password (pass). Default camera IP/user name/password: IP: 192.168.0.200 Username: admin Subnet Mask: 255.255.255.0 Password: pass Gateway: 192.168.0.1 iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 54: For Iphone Users
NAT on the router. Although it is not very convenient, but, it does not need to go through the network service platform, the security of the data can be ensured, and It is no need to worry about the IPCamplus APP being unavailable after the network service platform stops serving. iCAM-MR/ZMR Series User Manual ICP DAS... -
Page 55: For Android Users
NAT on the router. Although it is not very convenient, but, it does not need to go through the network service platform, the security of the data can be ensured, and It is no need to worry about the IPCamplus APP being unavailable after the network service platform stops serving. iCAM-MR/ZMR Series User Manual ICP DAS...
