7. Click Save.
The new layout is saved and will appear in the table of layouts on the Screen Editor
page.
8. Click Publish.
The new screen layout appears on the main display.
Formatting Screen Layout Widgets
VIA Connect provides different formatting options for each of the screen layout widgets
(elements). You can define the position, color, format (for date and time) and refresh time (for
Room Code) of these elements. In addition, you can display a customized DNS (Domain
Name System) name instead of the default room name, if local DNS services are supported
by the network and a DNS server is defined (see
Formatting Text
Format the following on the Properties tab:
▪
Enter the text in the text field.
▪
Select the font size and text alignment.
▪
Under Auto Resize, click ON to automatically resize the box to fit the size of the text.
When the layout is published, on the main display the box size adjusts to fit the size
of the text.
Format the following on the Color tab:
▪
Click the Background color box and select a fill color for the text box.
▪
Select the opacity of the text box.
▪
Click the Font Color box and select a font color.
▪
Under Border, click ON, click the Border Color box and select a border color.
Formatting Room Name 1
Room Name 1 is the address used join a meeting.
Format the following on the Properties tab:
▪
In the Room Name field, you can enter one or both of the following:
 #roomname# – Automatically displays the IP address of the meeting space
(default).
#airplayname# – Automatically displays the airplay name of the meeting space,

(see
on page 55).
▪
In the Custom Room Name field, enter a custom name for the meeting space. This
name appears in place of the meeting space IP address when #roomname# is used
in the Room Name field (see bullet above).
VIA Connect – For Web Administrator: Configuring Settings – Gateway Management Pages
Mirroring Apple Laptops and iPhones Using iOS/OS X Airplay Service
Changing LAN Settings
Kramer Electronics Ltd.
on page 43).
