Enable
Private IP
Choose PC
5.2.3 Open Ports
As Port Redirection (above) allows you to define a range of ports,
the following screen shows the Open Ports Setup. In the Vigor router,
the Open Ports facility provides 10 entries for internal hosts.
NAT Setup
Check to enable the DMZ Host function.
Enter the private IP address of the DMZ host.
Click this button and then a window will automatically pop
up, as depicted below. The window consists of a list of
private IP addresses of all hosts in your LAN network.
Select one private IP address in the list to be the DMZ host.
5-6
