3.2.1 Using PPPoE with a DSL modem
Click Internet Access Setup > PPPoE to enter the setup page.
PPPoE Setup
PPPoE Link: Check Enable to enable the PPPoE client protocol on
the WAN interface.
Please remember to remove PPPoE applications, which are already
installed on your PCs if you need to enable PPPoE and you are DSL
users.
ISP Access Setup
ISP Name: Enter the service name if provided by your ISP.
Username/Password: Enter the username and password supplied
by your ISP
Scheduler (1-15): Enter the index of schedule profile to control the
Internet access by time plan.
PPP/MP Setup
PPP Authentication: Select PAP or CHAP for widest compatibility.
Always On: Check to force the Internet access is always online, and
you will see the Idle Timeout field will be blocked for input.
Idle Timeout: Idle timeout means the router will disconnect after
Internet Access Setup
3-3
