11.1 Introduction
Diagnostic Tools provide a useful way to view or diagnose the status of
you Vigor router.
11.2 Settings
Click Diagnostics to open the setup page.
11.2.1
PPPoE/PPTP Diagnostics
Refresh
Broadband Access
Mode/Status
WAN IP Address
Dial PPPoE or
PPTP
Dial PPPoE or
PPTP
Diagnostic Setup
Diagnostics Setup
To obtain the latest information, click here to reload the
page.
Display the broadband access mode and status. If the
broadband connection is active, it will show PPPoE, PPTP,
Static IP, or DHCP Client depending on which access
mode is enabled. If the connection is idle, it will show "---".
The WAN IP address for the active connection.
Click it to force the router to establish a PPPoE or PPTP
connection.
Click it to force the router to establish a PPPoE or PPTP
connection.
11-1
Chapter 11
