Bender ISOMETER iso415R Manual page 25

Address Register name
(dec)
Control commands (60000)
60000 Function selection
Function 2: Find device
60000 Function selection
60001 Pattern value part 1
60002 Pattern value part 2
60003 Period
Function 4: Reset to factory settings/Reset parameters
60000 Function selection
60001 Pattern value part 1
60002 Pattern value part 2
60003 Type of reset
Function 6: Test
60000 Function selection
60001 Pattern value part 1
60002 Pattern value part 2
60003 Type of test
Data type Bytes Mode
Uint16 2 WO
Uint16 2 WO
Uint16 2 W0
Uint16 2 W0
Uint16 2 W0
Uint16 2 WO
Uint16 2 WO
Uint16 2 WO
Uint16 2 WO
Uint16 2 WO
Uint16 2 WO
Uint16 2 WO
Uint16 2 WO
Value/Unit/Comment
Function selection register to control the
function of the following registers. Only
specified values are permitted.
2 = Find device
4 = Reset to factory settings /
Reset parameters
6 = Test
7 = Reset
2 → Selection of the "Find device"
function
61918 → Safety pattern must be written
for the function to be executed
0 → Safety pattern must be written for the
function to be executed.
0...300 → Period in seconds during which
the device lights up. If the device receives
the value "0", the function is stopped.
4 → Selection of "Reset to factory
settings/Reset parameters" function
64199 → Safety pattern must be written
for the function to be executed
1304 → Safety pattern must be written for
the function to be executed
1 → Reset to factory settings including
interface parameters
2 → Reset to factory settings excluding
interface parameters
6 → Selection of the "Test" function
32343 --> Safety pattern must be written
for the function to be executed
0 → Safety pattern must be written for the
function to be executed
1 → Start IMD test
iso415R-x_D00401_00_M_XXEN / 04.2021
ISOMETER® iso415R
Factory
setting
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
25
