4.1.5 Detent potentiometer response value main alarm R

5 10
1
Ext 1k 700
Ran1 (kΩ)
5 10
Ext 700 400
Ran2 (kΩ)
Ext 700 400

4.1.6 T/R button

Ran2 (kΩ)
The T/R button activates different functions and editing modes depending on how long it is
pressed.
- A
T / R
11 12
Overview
1 s
- A
T / R
RESET
12

4.1.6.1 "RESET" function

The "RESET" function resets stored alarm states and disables the limit value hysteresis for that mo-
ment.

4.1.6.2 "TEST" function

The "TEST" function simulates an insulation fault for 5 seconds.
During this period, the device has the following states:
•
Display of the alarm value via the LEDs and the interface.
•
The relays switches when the alarm assignment "Test" has been activated.
•
The test status can be read out via the interface:
– 0 = no test, 1 = internal test (local), 2 = external test (interface)
•
t and t are set to 0 s for the duration of the test
on off
