2.2 Dimensions (vertical version unit)
The following table, referred to the figure, shows dimensions and weights of QRCE series (vertical version) and its
accessories.
Vertical configurations
C : supply air at lower and right side looking at the electrical panel (like in the drawing above)
D : supply air at lower and left side looking at the electrical panel
Model
L
H
W
X
Y
E
F
G
D1
D2
L1
L2
Weight (basic unit)
Weight (CCS/CDX)
Weight (PLM)
MIUM0018_REV06_ QRCE_20180312-MIUM-ENG-AQ
QRCE
500 1000
mm 1350 1470
mm 680 820
mm 330 370
mm 230 300
mm 225 265
mm 52.5 52.5
mm 46 46
mm 128 130
mm
mm 3/4" M 3/4" M
mm 350 400
mm 340 380
kg 85 105
kg 28/28 31/31
kg 21 23
CCS
(CDX)
Fresh air
Return air
1500 2000
1850 1850
1030 1460
455 455
390 600
350 350
52.5 52.5
46 46
158 170
1/2" M
3/4" M 3/4" M
400 400
460 460
175 230
35/35 42/42
26 30
ENG
Supply air
Exhaust air
3000 4000
2150 2150
1460 1840
590 590
590 780
485 485
52.5 52.5
55 55
170 170
1" M 1" M
502 502
580 580
290 360
52/52 58/58
39 44
