aerauliqa QRCE Series Installation, Operation And Maintenance Manual page 6

2 – D
IMENSIONS AND
2.1 Dimensions (horizontal version unit)
The following table, referred to the figure, shows dimensions and weights of QRCE series (horizontal version) and its
accessories.
PLM
Horizontal configurations
A : supply air at right side looking at the electrical panel (like in the drawing above)
B : supply air at left side looking at the electrical panel
Model
L
W
H
W1
X
Y
E
F
G
D1
D2
L1
L2
Weight (basic units)
Weight (CCS/CDX)
Weight (PLM)
MIUM0018_REV06_ QRCE_20180312-MIUM-ENG-AQ
W
EIGHTS
QRCE
500 1000
mm 1350 1470
mm 680 820
mm 330 370
mm 760 900
mm 230 300
mm 225 265
mm 52.5 52.5
mm 46 46
mm 128 130
mm
mm 3/4" M 3/4" M
mm 350 400
mm 340 380
kg 85 105
kg 28/28 31/31
kg 21 23
D2
Fresh air
CCS
(CDX)
Return air
D2
1500 2000
1850 1850
1030 1460
455 455
1110 1540
390 600
350 350
52.5 52.5
46 46
158 170
1/2" M
3/4" M 3/4" M
400 400
460 460
175 230
35/35 42/42
26 30
ENG
Supply air
Exhaust air
3000 4000
2150 2150
1460 1840
590 590
1540 1920
590 780
485 485
52.5 52.5
55 55
170 170
1" M 1" M
502 502
580 580
290 360
52/52 58/58
39 44
AQ_001523_02_0721
6
