Specifications
20
C H A P T E R T W E N T Y
Specifications
Product Description
Six performance modes are available for the "6 in 1" model MFC 6650MC:
Fax, Printer, Copier, Scanner, PC Fax and Message Center.
The MFC 4650 and MFC 7750 are "5 in 1" models Fax, Printer, Copier,
Scanner and PC Fax.
The MFC 4350 is a "3 in 1" model: Fax, Printer, Copier.

Fax Specifications

Compatibility
Coding System
Modem Speed
Document Input Width
Document Input Length
Scanning/Printing Width
Paper Size
Multi-purpose Sheet Feeder
Gray Scale
Polling Types
Contrast Control
ITU-T Group 3
MH/MR/MMR
14400 - 2400 bps (MFC 4350, MFC 4650 and MFC 6650MC)
33600 - 2400 bps (MFC 7750)
5.8 inches to 8.5 inches (148 mm to 216 mm)
3.9 inches to 14.1 inches (100 mm to 360 mm)
8.2 inches (208 mm)
Letter/Legal/A4
200 sheets (20 lbs)
64 levels
Standard or Sequential
Automatic/Super Light/Super Dark (manual setting)
227
