Technical Specifications

This section provides important technical specifications related to the device.
5.1

Power Supply Specifications

Note
When determining cable lengths, make sure the minimum input voltage for the
power supply is provided at the power source.
Supply Type
54 VDC
a
(T) denotes time-delay fuse
5.2

PoE Output Specifications

The RUGGEDCOM RST916P adheres to the following power output and IEEE 802.3
specifications depending on the input voltage supplied to the device.
5.3

Failsafe Alarm Relay Specifications

Hazardous Environments
Maximum Switching Voltage
RUGGEDCOM RST916P
Installation Manual, 04/2021, C79000-G8976-1489-01
Power Minimum
Input
52 VDC
Power In
52 to 57 VDC
52 to 57 VDC
52 to 57 VDC
30 VDC
250 VAC
Maximum Fuse Rating
Input
a
57 VDC 12 A (T)
Power Out Per Port (Maximum)
51 to 57 VDC
51 to 57 VDC
51 to 57 VDC
Rated
Switching
Current
2 A 5.0 kVAC
1.0 kVAC
2 A 5.0 kVAC
Isolation Maximum
Power
Consumption
1.5 kVDC 15 W
Specification
15 W IEEE 302.af/at
30 W IEEE 302.at
60 W IEEE 302.bt
Isolation
a
between coil and contacts
a
between contacts
a
between coil and contacts
5
Maximum
Combined
Power
Output at
PoE Ports
420 W
