Actuator with CANbus J1939:

CANbus (J1939)
Connection diagram:
Fig. 16 : 33xxxxxxxxxx3xxx=xxxxx007xxxxx
33XXXXXXX03XXX=XXXXX007XXXXX
INWARDS
M
OUTWARDS
H-Bridge
CAN_H
CAN_L
DATA
DATA GND
The BusLink software tool is available for CANbus actuators and can be used for:
Diagnostics, manual run and configuration
The newest version is available online at LINAK.COM/TECHLINE
Please note: The BusLink configuration cable must be purchased seperately
Item number for BusLink cable kit: 0367997 (adapter + USB2Lin)
BROWN 2
1
BLUE
BLACK 1
2
RED
5
YELLOW
6
GREEN
4
VIOLET
3
WHITE
18
Page 55 of 80
2019 © LINAK A/S
Powered by Danfoss
DEUTSCH
Standard signal cabel
