Feedback configurations available for IC Advanced, Proportional and Parallel

Pre-configured Customised
None
PWM Feedback 10 – 90 %
75 Hz
Single Hall N/A
Analogue 0 - 10V
Feedback
Voltage (AFV)
Analogue 4 - 20mA
Feedback
Current (AFC)
End Stop Signal At physical end
in/out* stops.
Default for IC
Advanced.
All feedback configurations are available for IC Advanced.
* With Parallel only the configuration 'End Stop Signal' is available through feedback
(Yellow and Green cables).
Pros
range
N/A
0 – 100 % Suitable for long distance
75 – 150 Hz transmission.
Effectual immunity to
electrical noise.
N/A Suitable for long distance
transmission.
Any combination, High resolution. Traditional
going negative or type of feedback suitable
positive. for most PLCs.
E.g. 8.5 – 2.2V Easy faultfinding.
over a full stroke.
Independent on stroke
length, compared to a
traditional mechanical
potentiometer.
Any combination, High resolution. Better
going negative or immunity to long cables
positive. and differences in
potentials than AFV.
E.g. 5.5 – 18mA
over a full stroke. Provides inherent error
condition detection.
Independent on stroke
length, compared to a
traditional mechanical
potentiometer.
Any position. Can be set at any position
over the full stroke length.
Page 45 of 80
Cons
N/A
More complex processing
required, compared to AFV
and AFC.
No position indication.
Not recommended
for applications with
long distance cables or
environments exposed to
electrical noise.
Higher power consumption
compared to AVF. Not
suitable for signal isolation.
Only one endstop can be
customised.
