Actuator with End Stop Signals and absolute positioning Analogue feedback

End Stop Signals and absolute positioning - Analogue feedback
Connection diagram:
33XXXXXXXX0AXXXX=XXXX1XXXXXXXX
Fig. 6 : 33xxxxxxxx0Axxxx=xxxx1xxxxxxxx
*YELLOW/GREEN: Endstop signals out are NOT potential free
Tip: If you wish to use the endstop signals, you will have to keep power on the brown, blue,
red and black wires, otherwise the signal will be lost.
The signal power must be
BROWN
BLUE
+
RED
YELLOW*
GREEN*
VIOLET
BLACK
-
turned on at all times when the actuator is running, and minimum one second before it starts to run.
Page 21 of 80
2019 © LINAK A/S
2
Powered by Danfoss
1
Standard signal cabel
2
5
6
Standard signal cabel
4
1
11
AMP
DEUTSCH
