Ac tuator with absolute positioning - PWM
Absolute positioning - PWM
I/O specifications:
Input/Output
Description The actuator can be equipped with electronic circuit that gives an
analogue feedback signal when the actuator moves.
Brown 12 or 24 VDC (+/-)
12 V ± 20 %
24 V ± 10 %
Under normal conditions:
12 V, max. 13 A depending on load
Blue
24 V, max. 9 A depending on load
Red Signal power supply (+) 12-24 VDC
Black Signal power supply GND (-)
Green Not to be connected
Yellow Not to be connected
Violet Digital output feedback (PNP)
10-90 % (Option 5)
20-80 % (Option 6)
White Not to be connected
For actuators with analogue feedback it is recommended to fully extract and retract the actuator on a regular basis (thereby
activating the limit switches) in order to ensure precise positioning.
Specification
12
Page 24 of 80
2021 © LINAK A/S
Comments
To extend actuator:
Connect Brown to positive
To retract actuator:
Connect Brown to negative
To extend actuator:
Connect Blue to negative
To retract actuator:
Connect Blue to positive
Current consumption:
Max. 60 mA, also when the
actuator is not running
Output voltage min. V IN - 2 V
Tolerances +/- 2 %
Max. current output: 12 mA
Frequency: 75 Hz
