Actuator with proportional control
I/O specifications:
Input/Output Specification
Green End Stop Signal out
Yellow End Stop Signal in
Violet Analogue feedback (0-10V):
Configure any high/low combination between
0-10V
Single Hall output (PNP):
Movement per Single Hall pulse:
33090: Actuator = 0.3 mm per count
33150: Actuator = 0.5 mm per count
33200: Actuator = 1.1 mm per count
Frequency: Frequency is up to 125 Hz on Single
Hall output depending on load and spindle.
Overvoltage on the motor can result in shorter
pulses
Digital output feedback PWM:
Configure any high/low combination between
0-100%
Analogue feedback (4-20mA):
Configure any high/low combination between
4-20mA
All absolute value feedbacks (0-10V, PWM and
4-20mA)
White Signal GND
Comments
Output voltage min. V
Source current max. 100mA
End Stop Signals are NOT potential free. End
Stop Signals can be configured with BusLink
software according to any position needed
When configuring virtual endstop, it is not
necessary to choose the position feedback.
End Stop Signal and virtual endstop will work
even when feedback is not chosen
Ripple max. 200mV
Transaction delay 20ms
Linear feedback 0.5%
Max. current output. 1mA
Output voltage min. V
Max. current output: 12mA
Max. 680nF
Output voltage min. V
Frequency: 75Hz ± 10Hz as standard, but this
can be customised.
Duty cycle: Any low/high combination between
0 and 100 percent.
Open collector source current max. 12mA
Tolerances ± 0.2mA
Transaction delay 20ms
Linear feedback 0.5%
Output: Source
Serial resistance: 12V max. 300 ohm
Standby power consumption:
12V, 85mA
24V, 50mA
It is recommendable to have the actuator to
activate its limit switches on a regular basis, to
ensure more precise positioning
For correct wiring of power GND and Signal
GND see page 37
